Zephyr Elica Concave ECO-M90AS Use, Care And Installation Manual page 7

15" 13/16
max 53" 8/16*
min 35" 5/16*
max 51" 4/16
min 35" 5/16
35" 5/16
35" 6/16
Side
Cabinet
* Ductless (recirculating) version ONLY
30" 5/16
8" 7/16
ceiling
11" 1/2
35" 7/16
min. cabinets opening widths
24" to 32"
bottom of canopy
to cooking surface CenterLine
7
www.zephyronline.com
17" 8/16
21" 3/16
Ø 13" 3/8
1" 7/8
4" 2/8*
Ducting
and conduit
3"
area
passage(Duct
bends are not
10"
considered)
23" 1/4
Side
Cabinet
1" 15/16
