4.4. MASTER MODULE

Menu
The function is used to register the EU-ML-12 slave controller in the EU-L-12 main controller. To do this:
•
For wired registration, connect the EU-ML-12 controller to the EU-L-12 controller following to the diagrams in the
manual
•
In the EU-L-12 controller, select:
•
In the EU-ML-12, select:
After registering the EU-ML-12 add-on module, users can control the operation of additional zones that the EU-ML-12 module
supports from the level of the main EU-L-12 controller and the Internet. Each EU-ML-12 controller allows the operation of a
further 8 zones. A maximum of 40 zones can be controlled by the system.
CAUTION
This function allows registration of up to 4 EU-ML-12 devices. Options of wired and wireless registration are
possible.
CAUTION
Registration will only be successful if the system versions* of the registered devices are compatible with each
other.
*system version – version of the device communication protocol

4.5. REPEATER FUNCTION

Menu
In order to use the repeater function:
1. Select registration Menu → Fitter's Menu
2. Start the registration on the transmitting device (e.g. EU-ML-12, EU-M-12).
3. After the correct execution of steps 1 and 2, the wait prompt on the EU-ML-12 controller should change from "Registration
step 1" to "Registration step 2", and on the registration of the transmitting device - "success". Every step of the registration
process is approx. 2 min.
4. Run the registration on the target device or on another device that supports repeater functions.
The user will be notified by an appropriate prompt about the positive or negative result of the registration process.
CAUTION
Registration should always be successful on both registered devices.
Fitter's Menu
Menu → Fitter's Menu → Additional Module → Module Type
Menu → Fitter's Menu→ Main Module → Module Type.
Fitter's Menu
→
Repeater function → Registration
