IV. FIRST STARTUP
In order for the controller to operate correctly, the following steps must be followed for the first start-up:
Step 1: Connect the EU-ML-12 mounting controller with all devices to be controlled
To connect the wires, remove the controller cover and then connect the wiring – this should be done as described on the
connectors and the diagrams in the manual.
Step 2. Switch on the power supply, checking the operation of the connected devices
After connecting all devices, switch on the power supply of the controller.
Using the Manual mode function
Using the and buttons, select the device and press the MENU button – the device to be checked should switch on.
Check all the connected devices in this manner.
Step 3. Set the current time and date
To set the current date and time, select:
CAUTION
If you are using the EU-505, EU-WiFi RS or EU-WiFi L module, the current time can be downloaded from the
network automatically.
Step 4. Configure temperature sensors, room controllers
In order for the EU-ML-12 controller to support a given zone, it must receive information about the current temperature.
The simplest way is to use a wired or wireless temperature sensor (e.g. EU-C-7p, EU-C-mini, EU-CL-mini, EU-C-8r). However,
if you wish to be able to change the set temperature value directly from the zone, you can use either room controllers:
e.g. EU-R-8b, EU-R-8z, EU-R-8b Plus or dedicated controllers: EU-R-12b, EU-R-12s, EU-F-12b, EU-R-X. To pair a sensor with
the controller, select: Menu → Fitter's menu → Zones →Zone... → Room sensor → Select sensor.
Step 5. Configure the EU-M-12 control panel and the EU-ML-12 add-on modules
The EU-ML-12 controller can utilize the EU-M-12 control panel, which performs a master function - through it, you can
change the set temperatures in the zones, and designate local and global weekly schedules, etc.
Only one control panel of this type may be installed in the installation, which must be registered in the main EU-L-12
controller: Menu → Fitter's menu → Control panel
slave ML-12 controller, this controller must be connected to the master L-12 controller, where the control panel is
registered.
In order to expand the number of supported zones in the installation (max, 4 additional modules), each EU-ML-12
controller should be separately registered in the main EU-L-12 controller by selecting:
modules → Module 1..4.
Step 6. Configure the remaining cooperating devices
The EU-ML-12 controller can also work with the following devices:
- EU-505, EU-WiFi RS or EU-WiFi L Internet modules (the emodul.eu application will display only zones supported by the
EU-ML-12 controller).
After connecting the Internet module, the user has the possibility to control the installation via the Internet and the
emodul.eu app. For configuration details, refer to the manual of the respective module.
- EU-i-1, EU-i-1m mixing valve modules
- additional contacts, e.g. EU-MW-1 (6 pcs per controller)
(Menu → Fitter's menu → Manual
Menu → Controller settings → Time
in order for the panel to display data on the zones operated by the
13
mode), check the operation of the individual devices.
settings.
Menu → Fitter's menu → Additional
