2.3. OPERATION MODE

The user has the ability to view and edit the operating mode settings for the zone.
•
Local Schedule – Schedule settings that only apply to this zone
•
Global Schedule 1-5 – These schedule settings apply to all zones, where they are active
•
Constant temperature (CON) - the function allows you to set a separate set temperature value, which will be valid
in a given zone permanently, regardless of the time of day
•
Time limit – the function allows you to set a separate temperature, which will be valid only for a specific period of
time. After this time, the temperature will result from the previously applicable mode (schedule or constant without
time limit).
1. Days on which the above settings apply
2. Temperature set outside the time intervals
3. Set temperatures for time intervals
4. Time intervals
To configure a schedule:
•
Use the arrows
week or 2nd part of week)
•
Use the MENU button to go to the set temperature settings, which will apply outside the time intervals - set it
using the arrows, confirm using the MENU button
•
Use the MENU button to go to the settings of the time intervals and the set temperature that will apply to the
specified time interval, set it using the arrows, confirm with the MENU button
•
Then proceed to the editing of the days that are to be assigned to 1st or 2nd part of the week, active days are
displayed in white. The settings are confirmed with the MENU button, the arrows navigate between each day.
Schedule editing
Menu → Zones → Zone... → Operation mode → Schedule... → Edit
to select the part of the week for which the set schedule will apply (1st part of the
4
3
17
1
2
