Ruby / Percy / Polly 2.0 / Polly light

3 Initial Operation, Using the Stove

First steps:
1. The stove must be connected to the flue. There must be a sufficient supply of combustion air.
2. Remove the accessories from the pellet hopper and the firebox. Fill the hopper with pellets and close
the hopper lid.
3. Plug in the power cable and set the toggle switch on the back of the stove to "I ".
4. The display will now show the Austroflamm logo. This is followed by the main operating menu with
temperature indicators and hopper level.
5. Before the initial start, it is necessary to fill the pellet screw conveyor. For more detailed information,
see section "Menu item: Manual pellet feed" below. This process can take up to 5 minutes.
6. To start the stove press "Start" on the display.

3.1 Operating the stove via touch display

Display − Room temperature indicator, various functions
Stove operating status
Tank level indicator
Smart Spot is
connected
By pressing the appropriate symbol, it is possible to switch to the desired setting or function.
The desired temperature can be set by pressing the buttons at 0.2 °C intervals between 5 °C and
40 °C. The setting is accepted immediately. The current room temperature is measured
necessary by the black, room- temperature sensor cable on the back of the
4
Target tempera-
ture
Error Warning
OFF
Current
room temperature
NOTE: A safety switch (in certain models)
monitors the correct closure of the hopper
lid and alarms the user if left open.
Timer active
Room temp.
Menu with
Delay timer
heat output setting
english
Temp. unit
Home screen
Standard
appliance.
