- Page 1 User manual RETRO 60 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions…………………………………………………………………………………3 Technical Specifications……………………………………………………………………………4 Control Menu ………………………………………………………………………………………4-6 DMX Channels ……………………………………………………………………………………6-7 Trouble Shooting……………………………………………………………………………………8 Fixture Cleaning………………………………………………………… …………………………8 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Voltage: AC100~220V 50/60HZ Power: 78W Light source: RGB 72X0.25W+ white 60W Control mode: DMX512, self-propelled, master-slave, voice control, with RDM function. Channel: CH10, CH4, CH73 Dimming: 32bit 0-100% linear dimming Working temperature: -30 ° C~50 ° C Strobe frequency: 1-30Hz IP level: IP20. - Page 5 Menu : After powering on, press the menu button and the menu menu will appear in sequence; Press the up or down button to modify the function parameters, and press the confirm button to save the current function and parameters (with power down memory after saving). Set the address code, modify it up or down (A001~A512), and save it with the confirm A001 A512...
-
Page 6: Dmx Channels
Factory settings When entering any address code from A001 to A512, press the menu button for 3 seconds to enter the factory settings. The factory settings mainly include the output power of each lamp, fan setting mode, temperature protection point setting, and parameter sending functions. In any mode, press the menu button for 3 seconds to exit。... - Page 7 channel Channel value basic function 000-255 Red bead linear dimming 000-255 Green bead linear dimming 000-255 Blue bead linear dimming 000-255 White Beads Linear Dimming CH73 channel Channel value effect 000-255 Group 1 Red Beads Linear Dimming 000-255 Group 1 Green Beads Linear Dimming 000-255 Group 1 Blue Beads Linear Dimming 000-255...
-
Page 8: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
