- Page 1 User manual MH 12X40 PIXEL BAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………6-8 Trouble Shooting…………………………………………………………………………………9 Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
3.Control Menu Menu Operation On the base of the control panel offers a number of features, such as setting DMX fixture address, switch the lamp, run the test program, the mode selection. Main menu Secondary menu hree-level menu/parameters parameters Dmx Address 001 - 512 Ch Mode STD/EXT... -
Page 6: Dmx Channels
Blue 0 - 255 White 0 - 255 Reset Run/OFF Fixture Reset Factory Run/OFF Language EN/CH Display Display Flip Normal/Reverse Display Mode Show/60s 4.DMX Channels 20 CH Mode 20CH Standard mode Channel name Channel value Channel content Tilt 0 - 255 Vertical rotation Tilt Fine 0 - 255... - Page 7 Built-in effect selection 0 - 10 no effect 11 - 13 Static effect 1 14 - 16 Static effect 2 … … … … 67 - 70 Static effect 20 71 - 72 Dynamic effect 1 Inner Effect 73 - 75 Dynamic effects 2 …...
- Page 8 208 - 212 turn on 213 - 225 Random slow strobe 226 - 238 Random medium speed strobe 239 - 251 Random fast strobe 252 - 255 turn on LED1 Red 0 - 255 LED1 red LED1 Green 0 - 255 LED1 green LED1 Blue 0 - 255...
-
Page 9: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
