- Page 1 User manual PIXEL IP20X15 BAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 2. Technical Specifications…………………………………………………………………………4 3. Installation…………………………………………………………………………………………5-6 4. Control Menu ………………………………………………………………………………………7 5. DMX Channels …………………………………………………………………………………8-10 6. Dimension…………………………………………………………………………………………11 7. Trouble Shooting…………………………………………………………………………………12 8. Fixture Cleaning………………………………………………………… ………………………12 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. • Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. -
Page 5: Installation
3. Installation Your IP24X15 BAR can be installed in every kind of following positions. Please see the explanations and rely to the instructions for a safe operation and secure handling. Structural Connection The IP24X15 BAR can be connected using the included quick-release pins. Place the devices next to each other. - Page 6 Horizontal hanging with tilt bracket You can attach the IP24X15 BAR to a Truss or Pipe. Notice that the tilt bracket(106mm) should face down from the hanging structure. Use the centered holes in the Tilt Bracket. You can use the additional fix Omega Brackets to hang the device horizontal. Hanging Vertically “dropped”...
-
Page 7: Control Menu
4.Control Menu Display: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions (unlock screen) Operations: Press "MENU" to unlock screen, then press “Menu” to select 7 different functions, Press the "UP or DOWN"keys to increase or decrease the value,Press "ENTER"... -
Page 8: Dmx Channels
5.DMX Channels Configuring DMX is described “Setting the DMX mode” on page 17. Channel Value Function 91CH 11CH 27CH 80CH Dimmer : 0-255 All dimmer Strobe : 0-255 Strobe from slow to fast Red : 0-255 Red dimmer Green : 0-255 Green dimmer Blue :... - Page 9 222-230 Macro25 ( … ) 231-239 Macro26 ( … ) 240-255 Macro27 ( … ) Macro Speed : 0-255 From slow to fast Dimmer Speed : 0-255 From slow to fast RGBW Backlight : 0-255 RGBW Backlight Colour Wheel : Empty 8-14 Rose...
- Page 10 White Dimmer LED16-20 : 0-255 Dimmer from dark to bright Red 1: 0-255 R1 dimmer Green 1: 0-255 G1 dimmer Blue 1: 0-255 B1 dimmer White 1: 0-255 W1 dimmer … … … … Red 20: 0-255 R20 dimmer Green 20: 0-255 G20 dimmer Blue 20:...
-
Page 11: Dimension
6.Dimension... -
Page 12: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
