Summary of Contents for Uplus Lighting PIXEL BAR 500
- Page 1 User manual PIXEL BAR 500 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions ......................... 3-4 Technical Specifications ........................4 Control Menu ............................5 DMX Channels ............................ 6-8 Dimension ............................... Trouble Shooting ..........................10 Fixture Cleaning ............................ 10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. . Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. . -
Page 5: Control Menu
4. Control Menu Display: To select the programming functions MENU To go backward in the selected functions DOWN To go forward in the selected functions ENTER To confirm the selected functions ( unlock screen) Operations: Press "MENU" to unlock screen, then press “Menu” to select 7 different functions, Press the "UP or DOWN"... -
Page 6: Dmx Channels
5.DMX Channels Mode Channel Function value Remark Master Dimmer 000 - 255 0 - 100% Duration 000 - 255 0 - 100% Strobe No function 000 - 010 From slow to fast 011 - 255 Flow Effect Effect 1- 5 000 - 255 Master Dimmer 000 - 255... - Page 7 Master Dimmer 000 - 255 0 - 100% Pixel-1 White 000 - 255 0 - 100% Pixel-1 Amber 000 - 255 0 - 100% Pixel-2 White 000 - 255 0 - 100% Pixel-2 Amber 000 - 255 0 - 100% Pixel-3 White 000 - 255 0 - 100%...
- Page 8 Pixel-1 000 - 255 0 - 100% Pixel-2 000 - 255 0 - 100% 10Ch Pixel-3 000 - 255 0 - 100% Pixel-4 000 - 255 0 - 100% Pixel-5 000 - 255 0 - 100% Pixel-6 000 - 255 0 - 100% Pixel-7 000 - 255...
-
Page 9: Dimension
6.Dimension... -
Page 10: Trouble Shooting
7 . Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1 . Check the connection of power and main fuse . 2 .
