  • Page 1 User manual IP 18X4 BAR Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6-8 Trouble Shooting…………………………………………………………………………………9 Fixture Cleaning………………………………………………………… ………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...

  • Page 3: Safety Instructions

    1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...

  • Page 4: Technical Specifications

    fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals.

  • Page 5: Control Menu

    3.Control Menu 1~Press MENU Can circulate 13different functions. The front 2Digits mean the function it has. (Please see the function form as follow.) And the last 2Digits mean the function’s address, speed or parameter. Press UP or DOWN can change the value. And press ENTERto confirm. 2~Press MENUmore than 2sec.

  • Page 6: Dmx Channels

    4.DMX Channels 10CH Mode Channel Function DMX Value Description Total Dimmer 0-255 Total Dimmer, dark to bright Total strobe 0-255 Total Flash strobe from slow to fast 0-10 No function 7Colors Jump Change；（Channel 6 Control Speed） 11-30 7Colors Gradate；（Channel 6 Control Speed） 31-50 Runing function Group；（Channel 6 Control Speed）...
  • Page 7 24 CH Mode Channel Function DMX Value Description Total Dimmer 0-255 Total Dimmer, dark to bright Total strobe 0-255 Total Flash strobe from slow to fast 0-10 No function 7Colors Jump Change；（Channel 6 Control Speed） 11-30 7Colors Gradate；（Channel 6 Control Speed） 31-50 Runing function Group；（Channel 6 Control Speed）...
  • Page 8 72 CH Mode Channel Function DMX Value Description R1 Dimmer 0-255 R1 Dimmer-Linear Dimmer. Dark to Bright G1 Dimmer 0-255 G1 Dimmer-Linear Dimmer. Dark to Bright B1 Dimmer 0-255 B1 Dimmer-Linear Dimmer. Dark to Bright W1 Dimmer 0-255 W1 Dimmer-Linear Dimmer. Dark to Bright R2 Dimmer 0-255 R2 Dimmer-Linear Dimmer.

  • Page 9: Trouble Shooting

    5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
