- Page 1 User manual IP 14X10 BAR Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4 DMX Channel ……………………………………………………………………………………5-6 Trouble Shooting…………………………………………………………………………………7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
2.Technical Specifications Light Source: 14x 4 IN1 RGBWY LED Beam angle: 25 degree Power:140W IP rate : IP65 Voltage: AC100~240V/50~60Hz Channels: 4ch\8ch\56ch\60ch Control Mode: Sound-Active. Master-Slave. Auto Running. DMX512 NW: 6.1 KGS Control Menu Function Show DMX Address（001—512） Addr A001-A512 UP、DOWN increase or reduce the value CHnd 4ch\8ch\56ch\60ch... -
Page 5: Dmx Channel
4.DMX Channels Channels Value Function Describe 0-255 R Dimmer R Dimmer-Linear Dimmer. Dark to Bright 0-255 G Dimmer G Dimmer-Linear Dimmer. Dark to Bright 0-255 B Dimmer B Dimmer-Linear Dimmer. Dark to Bright 0-255 W Dimmer W Dimmer-Linear Dimmer. Dark to Bright Channels Value Function... - Page 6 60CH Channels Value Function Describe 0-255 Total Dimmer Total Dimmer-Linear Dimmer. Dark to Bright 0-255 Total Strobe Total Flash Strobe. Slow to Fast 0-15 Function Choice1 16-255 Function Choice1 Running figure select 0-255 Speed Speed regulation 0-255 R1 Dimmer R1 Dimmer-Linear Dimmer. Dark to Bright 0-255 G1 Dimmer G1 Dimmer-Linear Dimmer.
-
Page 7: Trouble Shooting
5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
