- Page 1 User manual PIXEL BAR 1830 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels …………………………………………………………………………………6-9 Dimension…………………………………………………………………………………………9 Trouble Shooting…………………………………………………………………………………10 Fixture Cleaning………………………………………………………… ………………………10 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit. -
Page 4: Technical Specifications
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals. -
Page 5: Control Menu
4.Control Menu Display: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions (unlock screen) Operations: Press "MENU" to unlock screen, then press “Menu” to select 7 different functions, Press the "UP or DOWN"keys to increase or decrease the value,Press "ENTER"... -
Page 6: Dmx Channels
5.DMX Channels 11CH Channels Function Description Dimmer RGBWYUV master dimmer, 0~100% linear dimming,dark ->bright Strobe RGBWYUV master strobe, slow->fast 0--14： Empty 15--34： Color flow(Jump)（CH1--5 enable） 35--54： Color flow(Fade)（CH1--5 enable） 55--74： Color choose（CH1 enable） 75--94： Color Jump（CH1 enable） Macro1 95--114： Color fade,Color pulse（CH1 enable） 115--134：Effects 1（CH1 enable）... - Page 7 0--14： Empty 15--34： Color flow(Jump)（CH1--5 enable） 35--54： Color flow(Fade)（CH1--5 enable） 55--74： Color choose（CH1 enable） 75--94： Color Jump（CH1 enable） Macro1 95--114： Color fade,Color pulse（CH1 enable） 115--134：Effects 1（CH1 enable） 135--154：Effects2（CH1 enable） 155--174：Effects3（CH1 enable） 175--194：Effects4（CH1 enable） 195--214：Effects5（CH1 enable） 215--234：Effects6（CH1 enable） 235--255：Sound active（CH1 enable） 0--15：...
- Page 8 W1 dimmer W1 dimming,0~100% linear dimming,dark ->bright Y1 dimmer Y1 dimming,0~100% linear dimming,dark ->bright UV1 dimmer UV1 dimming,0~100% linear dimming,dark ->bright R2 dimmer R2 dimming,0~100% linear dimming,dark ->bright G2 dimmer G2 dimming,0~100% linear dimming,dark ->bright B2 dimmer B2 dimming,0~100% linear dimming,dark ->bright ..
-
Page 9: Dimension
UV dimmer UV dimming,0~100% linear dimming,dark ->bright(priority) CH11 R1 dimmer R1 dimming,0~100% linear dimming,dark ->bright CH12 G1 dimmer G1 dimming,0~100% linear dimming,dark ->bright CH13 B1 dimmer B1 dimming,0~100% linear dimming,dark ->bright CH14 W1 dimmer W1 dimming,0~100% linear dimming,dark ->bright CH15 Y1 dimmer Y1 dimming,0~100% linear dimming,dark ->bright CH16... -
Page 10: Trouble Shooting
7.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
