4-6.7 Integrated Peripherals

Integrated Peripherals option allows you to get some information inside
your system when it is working.
Run the Integrated Peripherals as follows:
1. Choose "Integrated Peripherals" from the Main Menu and a list of
options will appear:
AMIBIOS NEW SETUP UTILITY - VERSION 3.31a
Integrated Peripherals
Onboard IDE
Onboard LAN (Optional)
Onboard AC'97 Modem
Onboard FDC
Onboard Serial Port 1
Onboard Serial Port 2
Serial Port 2 Mode
Onboard Parallel Port
Parallel Port Mode
Parallel Port IRQ
Parallel Port DMA Channel
Onboard MIDI Port
MIDI Port IRQ
Onboard Game Port
K/B PowerOn Function
Stroke Keys Selected
PS/2 Mouse Power-on Function
F1: Help : Select Item
Esc: Previous Menu
2. Use one of the arrow keys to move between options and modify the
selected options by using PgUp / PgDn / + / - keys. An explanation
of the <F> keys follows:
<F1>: "Help" gives options available for each item.
<F9>: Setup BIOS default values.
<F10>: Save and Exit Setup.
3. Press <ESC> to return to the Main Menu when you finish setting up
all items. The following item descriptions are provided as a quick
guide to your setup.
Both
Enabled
Disabled
Auto
Auto
Auto
Normal
Auto
Normal
Auto
Auto
Disabled
5
200
Disabled
N/A
Disabled
+/- : Change Values
Enter: Select Sub-Menu
77
Chapter 4 BIOS Setup
Setup Help
F9: Setup Defaults
F10: Save and Exit
