Chapter 2 Hardware Setup - SOLTEK SL-85MR2 Manual

85MR2 / 85MR2-L

Chapter 2 Hardware Setup

To Get things ready for Hardware setup !
1. We recommend to install your CPU before any other components.
For detailed installation instructions of processor, you can also refer
to the pamphlet enclosed in your CPU package.
2. Installing a cooling fan with a good heatsink is a must for proper heat
dissipation for your CPU. Get ready an appropriate fan with heatsink
for proper installation. Improper fan and installation will damage your
CPU.
3. In case CPU Vcore, CPU clock or Frequency Ratio is adjustable on
board, please follow the instructions described in the User manual
for proper setup. Incorrect setting will cause damage to your CPU.
The following topics are included in this chapter:
2-1 Pentium 4 CPU and Installation
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 Install VGA / AGP4X with LED and Jumper
Safeguard
2-5 IDEConnector Installation
2-6 Floppy Disk Drive ( FDD) Installation
2-7 ATX 2.03 Power Supply Installation
2-8 Jumper Settings
2-9 Other Connectors Configuration
2-9 IRQ Description
16
