OPTICAL EYE DIAGRAMS
Figure 7. ADN2841 Unfiltered 2.5 Gbps Optical Eye.
Average Power = –3 dBm, Extinction Ratio = 10 dB.
Eye Obtained Using a Mitsubishi FU-445-SDF .
Figure 8. ADN2847 Unfiltered 2.5 Gbps Optical Eye.
Average Power = –3 dBm, Extinction Ratio = 10 dB.
Eye Obtained Using a Mitsubishi FU-445-SDF .
REV. 0
Figure 9. ADN2841 Filtered 2.5 Gbps Optical Eye.
Average Power = –3 dBm, Extinction Ratio = 10 dB.
Eye Obtained Using a Mitsubishi FU-445-SDF
Figure 10. ADN2847 Filtered 2.5 Gbps Optical Eye.
Average Power = –3 dBm, Extinction Ratio = 10 dB.
Eye Obtained Using a Mitsubishi FU-445-SDF .
