Flush Mount Presence Motion Sensor
HMW28/PRO
Low-bay
Product Description
HMW28/PRO is Microwave standalone motion sensor integrated with
Hytronik True presence detection technology, On/Off control with one relay
channel output, which is NO (normally open contact). The Hytronik True
presence detection technology works to detect human breathing rather than
the mirror movements. No matter if the person sit/stand statically or turns
their back to the sensor. The sensor can accurately recognize presence and
keeps the lights on all the time. It is ideal for typical indoor applications such
as classroom, of ce, healthcare, and other commercial areas.
Features
Store settings in the remote for easy commissioning when programming multiple sensors
One-Key
Commissioning
Intelligent photodiode - lights and sensors only operate when needed, natural light has proirity
Intelligent
Photodiode
Zero crossing detection to reduce in-rush current and maximise relay life
IP20/IP54 Ceiling/Surface mount box available as accessory
User-friendly design for installation
5 Year, 50,000hr Warranty
Technical Data
Input Characteristics
Model No.
Mains voltage
Stand-by power
Load ratings:
Capacitive
Resistive
Warming-up
Safety and EMC
EMC standard (EMC)
Safety standard (LVD)
Certi cation
Subject to change without notice.
HMW28/PRO
220~240VAC 50/60Hz
<0.3W
800VA
800W
20s
EN55015, EN61000
EN60669-1, EN60669-2-1
Semko, CB, CE , EMC, LVD, RCM
HF
Sensor Data
Model No.
Sensor Model
Detection range (Max.)*
Detection angle
* For more details of detection range, please refer to "detection pattern" section.
Environment
Operation temperature
IP rating
Edition: 20 Apr. 2023
IP20
HMW28/PRO
Presence Motion detection
Installation Height : 3m
Detection Range( Ø ) :10m
360
O
Ta: -20
O
C ~ +50
O
C
IP20
Ver. Draft
Page 1/5
Advertisement
Table of Contents
Related Manuals for Hytronik HMW28/PRO
Summary of Contents for Hytronik HMW28/PRO
- Page 1 HMW28/PRO is Microwave standalone motion sensor integrated with Hytronik True presence detection technology, On/Off control with one relay channel output, which is NO (normally open contact). The Hytronik True presence detection technology works to detect human breathing rather than the mirror movements. No matter if the person sit/stand statically or turns their back to the sensor.
-
Page 2: Mechanical Structure
Mechanical Structure Note: 1. We recommend the mounting distance between sensor to sensor should be more than 2m to prevent sensors from false-triggering. 2. The face-to-face installation between sensors and sensors or other radio sources is not recommended, or false trigger issue will potentially behave. Make sure the installed environment is free of any obvious vibration, strong air blows, curtain swing, water ow in pipe ……... -
Page 3: Detection Pattern
Detection Pattern Max: 3m Max: 3m Max: 5m Max: 5m insensitive sensitive Single person continuous walking Breathing detection When it’s in breathing & true presence detection mode and in sitting situation, facing to sensor directly will have a better detection range than 90 degrees side facing to sensor. Optional Accessory --- Ceiling/Surface Metal Mount Box: HA09/W, HA09/B, HA09/G 48.2 61.8... -
Page 4: Functions And Features
Functions and Features On/ off Control This sensor is a motion switch, which turns on the light upon detection of motion or breathing, and turns off after a pre-selected hold-time when there is no movement or breathing. A daylight sensor is also built in to prevent the light from switching on when there is suf cient natural light. - Page 5 Additional Information / Documents 1. Regarding precautions for PIR sensor installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Microwave Sensors - Precautions for Product Installation and Operation 2. Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy Subject to change without notice.
