Hytronik HMW28DCVFC/PRO Manual

Flush Mount Occupancy Motion Sensor
HMW28DCVFC/PRO
On/Off Control & Low-bay
Product Description
HMW28DCVFC/PRO is Microwave standalone motion sensor integrated
with Hytronik True occupancy detection technology, On/Off control with
one relay channel output, which is NO (normally open contact). The
Hytronik True occupancy detection technology works to detect human
breathing rather than the mirror movements. No matter if the person
sit/stand statically or turns their back to the sensor. The sensor accurately
recognizes occupancy and keeps the lights on continuously, making it highly
suitable for stable and peaceful environments such as of ces and hotels,
though not recommended for industrial settings.
Features
Store settings in the remote for easy commissioning when programming multiple sensors
One-Key
Commissioning
Intelligent photodiode - lights and sensors only operate when needed, natural light has proirity
Intelligent
Photodiode
Max withstandable in-rush current: 120A@160 s
VFC: Volt-free Contact/Dry Contact ON/OFF relay switch
− 24VDC@5A
− 250VAC@5A
Black & White & Gray metal surface mount box option
User-friendly design for installation
5 Year warranty
Technical Data
Input Characteristics
Input voltage
Stand-by power
Max withstandable
in-rush current
VFC: Volt-free Contact
/Dry Contact
Safety and EMC
EMC standard (EMC)
EN61547, EN55015,EN61000-3/2/-3-3
Safety standard (LVD) EN60669-1, EN60669-2-1
EN300 400, EN301489-1/-3/-17
RED
EN50663, EN30328
Certi cation
UKCA, CE, RCM
Subject to change without notice.
12~48 DC
30mA
120A@160 s
− 24VDC@5A
− 250VAC@5A
HF
Sensor Data
Sensor Model
Detection range (Max.)*
Detection angle
* For more details of detection range, please refer to "detection pattern" section.
Environment
Operation temperature
Storage temperature
IP rating
Relative humidity
Edition: 12 Step. 2024
R R E E D D
Occupancy Motion detection
Installation Height : 3m
Detection Range( Ø ) :10m
360 O
Ta: -20 O C ~ +50 O C
-40°C ~ +70°C
IP20
10 ~ 90%
Ver. A0 Page 1/5
