1 - PACKAGING

PACKAGE CONTENT

• 1x JETPAR7ZIP.
• 1x 1,5 meters power cable (BARE END - SEETRONIC POWERCON TRUE1 IP65).
• User Manual.

OPTIONAL ACCESSORIES

• AJP7ZIPBD: barn door with 8 directional flaps to adjust the light beam, ASTRA / JET PAR7ZIP.
• IPTESTBOX: portable vacuum and pressure tester for ProLights IP fixtures.
• C6002A/B: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt, aluminium / black.
• RSR0670A/B: steel security cable for hanging bodies, inox steel shackle, aluminium / black.
• WSBBF1G5: blackBox F-1 G5 transmitter, 2,45GHz & 5.2/5,8 GHz, DMX/RDM, 512Ch.
• WSBBF1G6: blackBox F-1 G6 transrec, 512ch, 2.45GHz, DMX&RDM,Bluetooth,G3,G4,G4S, G5, CRMX.
• WSBBR512G5: blackBox R-512 G5 receiver 512Ch, 2.45GHz & 5.8GHz, DMX/RDM optional.
• WSBBR512G6: blackBox R-512 G6 receiver 512Ch, 2.45GHz,DMX&RDM,Bluetooth,G3,G4,G4S,G5,CRMX.
• UPBOX2P5: firmware uploader kit, USB IN, 5-pin XLR DMX OUT.

2 - TECHNICAL DRAWING

Ø451 mm
[17.8 in]
292 mm 302 mm
[11.5 in] [11.9 in]
Weight: 9,3 kg - 20,50 lbs Fig. 01
PROLIGHTS - Jet PAR7ZIP
05
