Vision 230/260/280 User Guide

Removing and Inserting Your Slides

In order to reach the slides, you must move the rubber seal which is seated in back of the
operating panel.
Caution
Removing a Slide
Slides have tabs to allow the slide to be pulled out more easily.
1. Grasp the tab, with your fingers or using flat-bladed long-nose pliers.
2. Pull gently and steadily; the slide slowly slips out.
Inserting a Slide
•
Gently and steadily, slip the slide into the slot.
30
•
Slides fit very tightly into the operating panel slots. This
keeps the correct label over the correct key. When you
remove or insert slides, work carefully, as excessive force
may damage the slide.
