CANbus Wiring Specifications

Table 2:
CANbus Specifications
Power Requirements:
Galvanic Isolation
between CANbus and
controller:
Max. Network Cable Length:
1 Mbit/s -
500 Kbit/s -
250 Kbit/s -
125 Kbit/s -
100 Kbit/s -
50 Kbit/s -
20 Kbit/s
Note: If you require cable lengths over
500 meters, contact technical support.
Table 3:
Wiring Considerations
Use twisted-pair cable. DeviceNet®
thick shielded twisted pair cable is
recommended.
Network terminators: These are
supplied with the controller. Place
terminators at each end of the CANbus
network. Resistance must be set to 1%,
121Ω, 1/4W.
Connect ground signal to the earth at
only one point, near the power supply.
The network power supply need not be
at the end of the network
Maximum number of controllers in a
network: 63
24VDC (±4%),
40mA max. per unit
Yes
25 m
100 m
250 m
500 m
500 m
1000 m
1000 m
Chapter 5: Communications
24V Power
Supply
-
-V
L
PE
H
+V
-V
L
PE
H
+V
-V
L
PE
H
+V
121
terminating
resistor

Figure 10. CANbus Wiring Diagram

Circuit
protection
device
121
terminating
resistor
21
