RUNNING THE SOFTWARE WITHOUT HARDWARE

The software can run in standalone mode when no evaluation
board hardware is connected to the USB port.
1. Click Start > All Programs > Analog Devices > 8 & 10
Lead PulSAR ADCs.
2. The software automatically seeks to find the hardware
connected; therefore, when no hardware is connected, it
displays a connectivity error (see Figure 17). To continue
without hardware in standalone mode, click Cancel.
Figure 17. No Hardware Connected Pop-Up Window Error
8-/10-Lead PulSAR User Guide
3. The software alerts you that no hardware is connected, and
that the software will continue in standalone mode.
Figure 18. Software Indicates Operating in Standalone Mode
4. Within standalone/offline mode, you can load example
files or previously saved files and analyze these files.
5. If you decide to connect hardware at this point, close the
software and relaunch it to allow the software to search for
the board again.
