Introduction

1.1 Lactate Scout Vet measuring device

Opening (1A)
for inserting the Test Strip
Display (1B) Display screen
will indicate the following:
device ready, blood lactate concentration, warning
messages, configuration options and status
information.
Keypad for operating the measuring device
• Arrow keys (1C):
- for moving between menus, sub-menus and
menu items
- for adjusting values
• OK button (1D):
- for selecting menus, sub-menus and
menu items
- for confirming choices
- for activating and deactivating
configuration mode
• Back button (1E):
for undoing the last step/cancelling
• Temperature sensor (1F):
for reading the ambient temperature
9
1.2 Lactate Scout Test Strip
The Test Strip has an opening for the blood
sample (2A). The contacts
Test Strip to the measuring device.
1
1E 1C 1D
(2B)
connect the
1F
1A
1B
2A
2B
2
