EKF Diagnostics SensLab Lactate Scout Vet Instruction Manual page 23

Move the measuring device with the inserted
Test Strip to the droplet. Allow the droplet
to fill the measurement chamber until the
opening for the blood sample is immersed
in the droplet. An acoustic signal will sound
when the chamber has filled and the test
will begin.
You can track the progress of the test
5 6
7
on the display 5 . The measured lactate
concentration will be displayed and if the
result is within the permissible tolerance range,
a tick will be shown in the centre of the display
6 . Indicating that the device and Test Strip
are functioning properly. If the result is outside
of the tolerance range, an error message will
be displayed 7 (see chapter 5 on page 30,
"Functionality test not successful").
The device will turn off when the Test Strip
is removed.
