Settings, Functions And Displays - EKF Diagnostics SensLab Lactate Scout Vet Instruction Manual

3 Settings, functions and displays

Settings can be changed in Configuration and
Display mode. In order to access Configuration
and Display mode, there must not be a Test
Strip inserted in the measuring device. The
Configuration and Display mode can be
switched on or off by holding down the OK
button for two seconds. An acoustic signal will
sound, and the main menu will be displayed
along with its symbols. The symbols display
the sub-menus
• Stored test results
• Functionality test
• Test Strip code configuration
Choose a symbol to move to the associated
sub-menu:
- Set Date Time
(1E)
- Set Volume
- Info (1F)
17
:
1
(1A)
(1B)
(1C)
(1D)
Briefly press one of the two arrows to select
a symbol. The selected symbol is displayed
with a black background. Pressing the OK
button enters the sub-menu. Once changes
to the configuration are complete, confirm
selection by pressing the OK button to
return to the main menu. Pressing the Back
button will also return to the main menu
but changes to configuration will not be saved.
1A
1B
1F
1
1C
1D
1E
