POWER SUPPLY:

The devices can be powered between a wide range of tensions. For more details see the two
tables below.
HD67427-Exx-xxx
Consumption at 24V DC:
HD67437-Exx-xxx
Caution: Not reverse the polarity power
HD67437-E4x-xxx
Note: It is possible to use also negative tensions. In this case the polarity must be
inverted.
ADFweb.com Srl – IT31010 – Mareno – Treviso
VAC
Vmin Vmax Vmin
8V 26V
Device W/VA
HD67437-E7x-xxx
User Manual J1939 / PROFIBUS Slave
Document code: MN67437_ENG
VDC
Vmax
10V 40V
4
INFO: www.adfweb.com
Revision 1.001 Page 8 of 27
Connector1:
Power Supply port
0V
0V = Ground
+V
+V = Positive wire
V AC: min 8V ; max 26V
V DC: min 10V ; max 40V
Connector1:
+V 0V
Power Supply port
0V = Ground
+V = Positive wire
V AC: min 8V ; max 26V
V DC: min 10V ; max 40V
