CHARACTERISTICS:
The "HD67437" series are rugged devices used to interface J1939 devices with PROFIBUS Master.
With his particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal,
vertical, oblique).
It is possible to have the device varnished or totally resined and also in both cases with "Mini-Fit®" connectors or "AMP SuperSeal 1.5"
connectors. If is resined, the enclosure, like the "AMP SuperSeal 1.5" connectors, is waterproof (IP67).
The Configurable J1939 / PROFIBUS Slave - Converter allows the following characteristics:
Triple 4kV isolation between Power Supply / PROFIBUS / J1939;
Varnished / Resined (optionally);
Wide power supply input range: 8...26V AC | 10...40V DC;
Mini-Fit® / AMP SuperSeal 1.5 connectors;
Metal enclosure with fixing lugs;
Possibility to use Metal hose clamps for fixing it without using lugs;
Microprocessor for data control;
Wide temperature range: -40°C / 105°C (-40°F / 221°F).
CONFIGURATION:
You need Compositor SW67437 software on your PC in order to perform the following:
Define the parameter of the J1939;
Define the parameter of the PROFIBUS;
Receive J1939 frames;
Transmit J1939 frames;
Create a GSD File;
Update the device.
