Table 13. Daughterboard Extension Connector Cn5 - ST STM32100B-EVAL User Manual

Connectors
Table 12.
Pin Description
46 PD14
48 +3V3
50 GND
Table 13.
Pin Description
1 GND
3 NC
5 PE6
7 PE4
9 PC13
11 RESET#
13 PE1
15 PB9
17 PB7
19 D5V
21 PB4
23 NC
25 PD6
27 PD4
29 PD3
31 PD1
33 PC12
35 PC10
37 PA14
39 GND
41 PA12
43 PA10
45 PA8
47 PC8
49 PC6
2 NC
4 PC13
20/45
Daughterboard extension connector CN4 (continued)
Alternate function
Joystick Down
-
-
Daughterboard extension connector CN5
Alternate function
-
-
-
-
Tamper Key
RESET# button
Joystick Right
User button
Temperature sensor_SDA
-
Debug nTRST
-
USART2_RX
USART2_RTS
USART2_CTS
-
MicroSD card_CS
IrDA_TX
Debug TCK/SWCLK
-
-
USART1_RX
MCO
LED3
LED1
Tamper button
Doc ID 16533 Rev 3
How to disconnect from function block on
STM32100B-EVAL board
Remove R39
-
-
How to disconnect from component on
STM32100B-EVAL board
-
-
-
Remove R37
-
Remove R41
Remove R46
Remove R47
-
-
-
Remove R81
Remove R15
Remove R82
-
Remove R90
-
-
-
-
Remove R115 (not existent on PCB rev A)
-
Remove R61
Remove R59
Remove R637
UM0841
