Summary of Contents for DFI DT200-CS
- Page 1 DT200-CS MiniITX System with MXM User’s Manual © March 28, 2023 DFI Inc.
- Page 2 1. The changes or modifications not expressly approved by the party responsible for com- are the properties of the respective owners. pliance could void the user’s authority to operate the equipment. 2. Shielded interface cables must be used in order to comply with the emission limits. User's Manual | DT200-CS...
-
Page 3: Table Of Contents
Trusted Computing ......................30 NCT5525D Super IO Configuration ................30 NCT5525D Super IO Configuration ► Serial Port 1, 2 Configuration ....31 NCT5525D HW Monitor ....................31 NCT5525D HW Monitor ► Smart FAN Function ..........32 Serial Port Console Redirection ...................32 User's Manual | DT200-CS... - Page 4 The manual is subject to change and update without notice, and may be based on editions that do not resemble your actual products. Please visit our website or contact our sales representa- • 1 DT200-CS System Unit tives for the latest editions. •...
- Page 5 Make sure the system is placed or mounted correctly and stably to prevent the chance of dropping or falling may cause damage. • The openings on the system shall not be blocked and shall be kept in distance from User's Manual | DT200-CS...
-
Page 6: Chapter 1 - Introduction
Chapter 1 - Introduction X Overview Front View Rear View DC-in MIC-In USB 2.0 Power Button HDMI Port Line-Out 2.5" SSD Slot Power LED DP (From MXM) Grounding HDD LED Giga LAN USB 3.0 COM1 COM2 User's Manual | DT200-CS... -
Page 7: Dimensions
Dimensions (W x H x D): 320 x 220 x 87mm (2U) AI Accelerated: Up to 115W GPU MXM module supported Scalability: 3 M.2 expansion slots Support 5G Communication: Support M.2 B key 3052 5G cellular module User's Manual | DT200-CS... -
Page 8: Specifications
1 x M.2 E key supports 2230 slot (PCIe x1/USB2.0) AUDIO Audio Codec 5.1 CH Audio Codec:Realtek ALC888S-VD2-GR ETHERNET Controller 1 x Intel® I219LM for Q370 / I219V for H310 3 x Intel® I210AT Indicators 1 x PWD LED 1 x HDD LED User's Manual | DT200-CS... - Page 9 (W x H x D) Weight ENVIRONMENT Operating 0 to 55°C Temperature Storage Tem- 0 to 86°C perature Relative 5 to 95% RH (non-condensing)uminum extrusion + Metal Humidity STANDARDS AND Certifications CE, FCC Class A, RoHS CERTIFICATIONS User's Manual | DT200-CS...
-
Page 10: Chapter 2 - Hardware Installations
Remove the screws and put them in a safe place for later use. Front View Step 3: The boards can be easily accessed after the chassis cover is removed. Rear View Left View Right View User's Manual | DT200-CS... -
Page 11: Installing An M.2 Card
Lift the cover to open the system. Step 1: There are 4 screws on the bottom of the system are used to secure the M.2 cover to the chassis. Remove the screws and put them in a safe place for later use. User's Manual | DT200-CS... -
Page 12: Installing An Mxm Card
Screw tight the card onto the stand-off with a screw driver and a stand-off screw until the gap between the card and the stand-off closes up. The card should be lying parallel to the board when it’s correctly mounted. User's Manual | DT200-CS... - Page 13 Insert an MXM card into the socket at an angle while making sure the notch and key are per- closes up. The card should be lying parallel to the board when it’s correctly mounted. fectly aligned. User's Manual | DT200-CS...
- Page 14 Step 1: Connect the cable to the fan connector on the board. Align the mounting screws of the cooler with the mounting holes of the module. Tighten four screws to install the cooler onto the module. User's Manual | DT200-CS...
- Page 15 612-M3T300-000G 80W, 1290 CUDA Cores, 5.4 TFLOPS, 0~55°C MXM Quadro RTX3000 Fan PWR Y-cable for 1*3P/2.5mm to 1*3P/2.54mm to A81-009614-016G MXM(RTX3000) 1*4P/1.25mm, L=50mm MXM cooler for RTX3000 87x106.35x34 A71-110100-000G MXM Cooler MXM cooler for T1000 73x60x32.1mm User's Manual | DT200-CS...
-
Page 16: Installing An Antenna
There are antenna holes reserved on both the right and left sides of the system and by default covered by rubber plugs. Please remove the plug prior to installing an Antenna antenna. Chassis Wall Module Connector Cable Antenna Connector Washer User's Manual | DT200-CS... -
Page 17: Insterting A 2.5" Hdd/Sdd
Close the drive latch to lock the drive in place. Step 2: Pull the silver latch to unlock the door. Important: Excessive force may damage its mechanical parts. If the HDD/SSD is inserted backward into the slot, forcing the device may damage the slot. User's Manual | DT200-CS... -
Page 18: Mounting Options
Screw on the two brackets onto the system with six screws as illustrated below. 357.00 346.00 300.40 Wall Mount Bracket Wall Mount Bracket User's Manual | DT200-CS... -
Page 19: Chapter 3 - System Settings
ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the system chassis. If a wrist strap is unavailable, establish and maintain contact with the system chassis throughout any procedures requiring ESD protection. User's Manual | DT200-CS... -
Page 20: Jumper Settings
X Jumper Settings M.2 Power Clear CMOS Jumper USB2_5/6 COM1 COM2 USB2_5/6 COM1 COM2 LAN1 LAN1 AUDIO AUDIO „ 1-2 On: Normal (default) „ 2-3 On: Clear CMOS Data „ 1-2 On: 3V3SB (default) „ 2-3 On: 3V3 User's Manual | DT200-CS... -
Page 21: Pin Assignment
Chapter 3 BOARD SETTINGS X Pin Assignment CPU Fan USB2_5/6 USB2_5/6 COM1 COM2 USB2_5/6 COM1 COM2 LAN1 LAN1 AUDIO AUDIO Assignment Assignment Assignment SBV4 SBV4 Ground USBP_C_5N USBP_C_6N USBP_C_5P USBP_C_6P CTRL User's Manual | DT200-CS... -
Page 22: Com (Serial) Port
Front Panel USB2_5/6 USB2_5/6 COM1 COM2 COM1 COM2 LAN1 LAN1 AUDIO AUDIO Assignment Pin Assignment Assignment Assignment V_SUS_LED MDCD1(2)- MRD1(2) Power/ Standby V_SUS_LED MTD1(2) MDTR1(2)- HDD-LED HD_LED SUS_LED MDSR1(2)- MRTS1(2)- MCTS1(2)- Power RESET Button MRI1(2)- SYS_RST PWR_BTN- User's Manual | DT200-CS... -
Page 23: Lpc
DIO (Digital I/O) USB2_5/6 COM1 COM2 USB2_5/6 COM1 COM2 LAN1 LAN1 AUDIO AUDIO Assignment Assignment Assignment Assignment LAD1 D_IOA0_C D_IOA1_C RST# LAD0 D_IOA2_C D_IOA3_C FRAME# VCC3 D_IOA4_C D_IOA5_C LAD3 GND1 D_IOA6_C D_IOA7_C LAD2 SERIRQ GND2 5VSB User's Manual | DT200-CS... -
Page 24: Dio Power
Chapter 3 BOARD SETTINGS DIO Power Front Audio USB2_5/6 USB2_5/6 COM1 COM2 COM1 COM2 LAN1 LAN1 AUDIO AUDIO Assignment Assignment Assignment Mic2-L Mic2-R N.C. Line2-R Mic2-JD 5VSB Line2-L Line2-JD User's Manual | DT200-CS... -
Page 25: Sata Power
Chapter 3 BOARD SETTINGS SATA Power SATA (Serial ATA) USB2_5/6 USB2_5/6 COM1 COM2 COM1 COM2 LAN1 LAN1 AUDIO AUDIO Assignment Assignment User's Manual | DT200-CS... -
Page 26: Chapter 4 - Bios Settings
When “X” appears on the left of a particular field, it indicates that a submenu which contains additional options are available for that field. To display the submenu, move the highlight to that field and press <Enter>. User's Manual | DT200-CS... -
Page 27: Main
The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays min- utes from 00 to 59. Second displays seconds from 00 to 59. User's Manual | DT200-CS... -
Page 28: Rc Acpi Configuration
The system enter soft-off state after power failure. Power-on signal input is abled, only one thread per enabled core is enabled. required to power up the system. Last State The system returns to the last state right before power failure. User's Manual | DT200-CS... -
Page 29: Power & Performance
Enable or disable CPU Power Management. It allows CPU to enter "C states" when it’s idle and ME Unconfig on RTC Clear nothing is executing. When disabled, ME will not be unconfigured on RTC Clear. Note: The sub-menus are detailed in following sections. User's Manual | DT200-CS... -
Page 30: Trusted Computing
Set SuperIO WatchDog Timer Timeout value. The range is from 0 (disabled) to 255. To clear the existing TPM encryption, select "TPM Clear" and restart the system. This field is not available when "Security Device Support" is disabled. Note: The sub-menus are detailed in following sections. User's Manual | DT200-CS... -
Page 31: Nct5525D Super Io Configuration ► Serial Port 1, 2 Configuration
This section displays the system’s health information, i.e. voltage readings, CPU and system temperatures, and fan speed readings Serial Port Enable or disable serial port. Electrical Interface Mode Choose mode between RS232 / RS485 / RS422 User's Manual | DT200-CS... -
Page 32: Nct5525D Hw Monitor ► Smart Fan Function
SYS Smart Fan/CPU Smart Fan Control = [Disabled] • Fix Fan Speed Count Set the fan speed, the value ranging from 1-100%, 100% being full speed. The fans will always operate at the specified speed regardless of gauged temperatures. User's Manual | DT200-CS... -
Page 33: Serial Port Console Redirection Usb Configuration
Select parity bits: None, Even, Odd, Mark or Space. Enable or disable USB Mass Storage Driver Support. Stop Bits Select stop bits: 1 bit or 2 bits. Flow Control Select flow control type: None or RTS/CTS. User's Manual | DT200-CS... -
Page 34: Csm Configuration
USB Power Control CSM Configuration CSM (Compatibility Support Module) Support USB Power 5V_Dual: Support system wake from S3/S4 by USB KB&MS Enable or disable CSM Support. 5V: No Support system wake from S3/S4 by USB KB&MS User's Manual | DT200-CS... -
Page 35: Network Stack Configuration
Set the wait time in seconds to press ESC key to abort the PXE boot. Use either +/- or numeric keys to set the value. Media detect count Set the number of times the presence of media will be checked. Use either +/- or numeric keys to set the value. User's Manual | DT200-CS... -
Page 36: Chipset
Select which of IGFX/PEG/PCI Graphics device to be the primary display. PCIE Resizable BAR Support Enable/Disable PCIE Resizable BAR Support. If disable adjust EnableAbove4GBMmio option accordingly Internal Graphics Keep IGFX "Enabled" or "Disabled" based on the setup options, or select "Auto" for auto-detec- tion. User's Manual | DT200-CS... -
Page 37: Peg Port Configuration
PEG Port Configuration PEG Port Configuration ► PEG Port Feature Configuration Detect Non-Compliance Device Enable Root Port Detect Non-Compliance PCI Express Device in PEG Enable/Disable the Root Port Max Link Speed Configure PEG 0:1:0 Max Speed User's Manual | DT200-CS... -
Page 38: Peg Port Configuration Pch-Io Configuration
Teton Glacier Mode Switch between Dynamic Configuration for Teton Glacier Enable or Disabled. PCI Express Configuration PCI Express Configuration Settings SATA And RST Configuration SATA Device Otpions Settings HD Audio Configuration HD Audio Subsystem Configuration Settings User's Manual | DT200-CS... -
Page 39: Pch-Io Configuration ► Pci Express Configuration
This option allows you to create RAID or Intel Rapid Storage configuration along with Intel® Optane™ system acceleration on Serial ATA devices. Ports and Hot Plug Enable or disable the Serial ATA port and its hot plug function. User's Manual | DT200-CS... -
Page 40: Pch-Io Configuration ► Hd Audio Configuration
Chapter 4 BIOS SETTINGS Chipset PCH-IO Configuration ► HD Audio Configuration HD Audio Control the detection of the HD Audio device. Disabled HDA will be unconditionally disabled. Enabled HDA will be unconditionally enabled. User's Manual | DT200-CS... -
Page 41: Security
Clear the database from the NVRAM, including all the keys and signatures installed in the Key Management menu. Press Enter and a prompt will show up for you to confirm. Key Management Enables expert users to modify Secure Boot Policy variables without full authentication. User's Manual | DT200-CS... -
Page 42: Boot
Select this option to save BIOS configuration settings to a USB flash device. ► Restore Setting from file This field will appear only when a USB flash device is detected. Select this field to restore set- ting from the USB flash device. User's Manual | DT200-CS... -
Page 43: Updating The Bios
MAC address should be burned or not. c. After updating unique MAC Address from manufacturing, NVM will be protected immediately after power cycle. Users cannot update NVM or MAC address. User's Manual | DT200-CS...
