Motor and Controller Compatibility

Part # Controller Version
239657 A (Daisy Chain) (Fig. 8)
211852
326876 8 Amp (Fig. 13)
NOTe: Always replace the motor in the system with the same motor except the Round-Square Plate
(Fig. 16), which is obsolete. That motor will be replaced with the Round-Round (Fig. 15A, 15B).
NOTe: (*) denotes that (2) new motor harnesses MUST be ordered, and re-wiring instructions MUST be
used. See page 13.
Fig. 8
NOTe: Ensure that a 300:1
motor is replaced with a
300:1 motor (Fig. 15A),
and that a 500:1 motor
is replaced with a 500:1
motor (Fig. 15B).
Rev: 06.14.2016
B (Fig. 9)
C (Fig. 10)
C1 (Fig.11)
C2 (Fig. 12)
Fig. 9
Fig. 12
Fig. 15A - 236575, 300:1
Controller
Replacement
A Only
B/C2* Only
C/C2* Only
C1/C2* Only
C2
8 Amp Only
Fig. 10
Fig. 13 Fig. 14 - 229466
Fig. 15B - 287298, 500:1
Page 7
Motor(s) Used
Round-Square (Fig. 14), Round-
Round (Fig. 15A)
Round Square (Fig. 14)
Round-Round (Fig. 15A, 15B), Round-
Square Plate (Fig. 16)
Round-Round (Fig.15B)
Fig. 16 - Obsolete
IN-WALL® Slide-out Service Manual
Fig. 11
