- Page 1 Import Bike Rack OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Failure to acknowledge bike rack weight ratings may result in damage to the trailer. The Import Bike Rack can be provided with either an under bumper mounting configuration (432223), or an over bumper mounting configuration (432336). The bike rack can also be equipped with an optional bolt-on under- mount tire carrier (432585) and vertical mounting tube (118478) to help secure bicycles. -
Page 3: Resources Required
Marker Preparation Under Bumper Attachment NOTe: If using the under-mount attachment (Fig. 1) assembly (432223) to connect the bike rack, verify that the chassis was equipped with the necessary assembly bracket mount. Over Bumper Attachment NOTe: If using the over-mount attachment (Fig. 2) assembly (432336) to connect the bike rack, verify that the chassis was not equipped with the under-mount assembly brackets. - Page 4 Locate the following on the trailer: the frame rails (Fig. 4A), the bumper bracket (Fig. 4B) and the bumper (Fig. 4C). Fig. 4 Bolt on the weld-on brackets (Fig. 5A) to the bike rack support arm (Fig. 5B), using 4 supplied 3/8”-16 x 1 1/2”...
- Page 5 Lift the bike rack support arm, with weld-on brackets attached, and center the assembly on the frame rails. While supporting the bike rack support arm, outline the weld-on bracket placement onto the frame rail with a marker. NOTe: A minimum of 4" is needed for the bike rack to be stored in the closed and upright position (Fig. 5). Disassemble the weld-on brackets from the support arm.
-
Page 6: Over Bumper Attachment Assembly
Over Bumper Attachment Assembly NOTe: Verify that trailer is not equipped with the weld-on brackets (Fig. 3). The trailer MUST NOT have these brackets in order to complete the installation of the over bumper bike rack brackets. If the brackets are present, either grind off the weld-on brackets or order the under bumper bike rack attachments. - Page 7 Repeat step 1-6 with the remaining curbside bike rack bracket. Once the bike rack bracket is secured onto the chassis frame rails, the Light Bolt-on Bike Rack can be attached to the bike rack bracket assembly. Lift the bike rack up so that it is perpendicular (Fig. 12A) to the bike rack bracket assembly (Fig. 12B). Fig.
-
Page 8: Bike Rack Accessories
Bike Rack Accessories Failure to acknowledge tire carrier weight ratings may result in damage to the trailer. Lippert spare tire carriers are not intended to be used for more than one spare tire. The combined weight of the spare tire carrier and tire must not exceed a total weight of 100 lbs. -
Page 9: Optional Vertical Bike Support Bracket
Optional Vertical Bike Support Bracket Remove the snapper pin (Fig. 15A) from the mounting tube (Fig. 15B). Rotate the mounting tube vertically (Fig. 16A) and place it in the mounting bracket (Fig. 16B). Fig. 15 Fig. 16 Insert the snapper pin completely through the mounting bracket and tube holes (Fig. 17A). NOTe: Make sure the snapper pin is securely fastened and that the bike rack is stable. - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
