Getting started

1 Getting started
1.1

Package

The STM32-based camera with a ZigBee connectivity package (STEVAL-IFV001V1)
includes the following items:
● Hardware content
– Demonstration board fitted with camera, micro SD card, and ZigBee module (also
called camera unit).
●
Firmware
– Programmed in the system
– Object files of the firmware
● Documentation
– User manual (this document)
Note: The other hardware board (the monitoring unit) is available with the order code: STEVAL-
CCM003V1
1.2

Hardware setup

1. Power the camera unit first
2. Then wait for 2 to 3 seconds
3. Then power the monitoring unit.
1.2.1

Setting the camera unit

The camera unit is shown in
from a battery. The slider switch (SW3) present on the board is used for selecting the power
source. Before powering up the system, set this switch to the appropriate position, as per
Table 1:
Table 1.
4/33
www.BDTIC.com/ST
Figure
Power source setting
Switch (SW3) position
1-2
2-3
Doc ID 17087 Rev 1
1. This unit can be powered up either through a USB or
UM0908
Power source
USB
Battery
