3. Hardware

The core of the BB52 Explorer Kit is the EFM8BB52 Busy Bee 8-bit microcontroller. Refer to section
ment and layout of the hardware components.

3.1 Block Diagram

An overview of the BB52 Explorer Kit is illustrated in the figure below.
External connectivity
Breakout Pads
Serial Flash
silabs.com | Building a more connected world.
Debugging
USB Micro-B Debugger
Connector
EFM8BB52
Expandability
Qwiic
Temperature Ambient
Connector
& Humidity Light & UV
Sensor Sensor
Figure 3.1. Kit Block Diagram
J-Link
mikroBUS
Socket
Hall Effect
Sensor
UG512: BB52 Explorer Kit User's Guide
Hardware
1.4 Kit Hardware Layout for place-
Button and LED
User Button
& LED
Rev. 1.0 | 6
