1.4 Kit Hardware Layout

The layout of the BB52 Explorer Kit is shown below.
mikroBUS Socket
silabs.com | Building a more connected world.
Top View
LED
Push Button
Breakout Pads
USB Micro-B Connector
- Virtual COM port
- Debug access
- Packet trace
Figure 1.1. BB52 Explorer Kit Hardware Layout
35.6 mm
EFM8BB52
Reset Button
Qwiic
Connector
On-board USB
J-Link Debugger
UG512: BB52 Explorer Kit User's Guide
Introduction
55.9 mm
