MGM13S12 Module Radio Board
BRD4305E Reference Manual
The BRD4305E Mighty Gecko Radio Board contains a Mighty Gecko MGM13S12 mod-
ule which integrates Silicon Labs' EFR32MG13 Mighty Gecko SoC into a small form fac-
tor System-in-Package (SiP) module. The fully certified module contains all components
(a high-performance transceiver, an energy efficient 32-bit MCU, HF crystal, RF pas-
sives, and antenna) required for a system-level implementation of Zigbee, Thread, Blue-
®
tooth
Low Energy, and proprietary wireless networks operating in the 2.4 GHz band
with 18 dBm output power.
The BRD4305E Mighty Gecko Radio Board plugs into the Wireless Starter Kit Main-
board, which is included with the Mighty Gecko Starter Kit and gives access to display,
buttons, and additional features from expansion boards. With the supporting Simplicity
Studio suite of tools, developers can take advantage of graphical wireless application
development, mesh networking debug and packet trace, and visual energy profiling and
optimization.
This document contains a brief introduction and description of the BRD4305E Radio
Board features, focusing on the RF performance.
silabs.com | Building a more connected world.
RADIO BOARD FEATURES
• Wireless Module: MGM13S12F512GA
• CPU core: ARM Cortex
®
-M4 with FPU
• Flash memory: 512 kB
• RAM: 64 kB
• Operation frequency: 2.4 GHz
• Transmit power: 18 dBm
• Integrated chip antenna, RF matching
network, HF crystal, and decoupling
• Option for UFL connector
• Crystal for LFXO: 32.768 kHz
• 8 Mbit low-power serial flash for over-the-
air updates
Rev. 1.0
Advertisement
Table of Contents
Related Manuals for Silicon Laboratories BRD4305E
Summary of Contents for Silicon Laboratories BRD4305E
- Page 1 • RAM: 64 kB • Operation frequency: 2.4 GHz The BRD4305E Mighty Gecko Radio Board plugs into the Wireless Starter Kit Main- board, which is included with the Mighty Gecko Starter Kit and gives access to display, • Transmit power: 18 dBm buttons, and additional features from expansion boards.
-
Page 2: Table Of Contents
Table of Contents 1. Introduction ....... . 3 2. Radio Board Connector ......4 2.1 Introduction. -
Page 3: Introduction
The BRD4305E Radio Boards provide a development platform (together with the Wireless Starter Kit Mainboard) for the Silicon Labs Mighty Gecko MGM13S12 modules. By carrying the MGM13S12 module, the BRD4305E Radio Board is designed to operate in the 2400-2483.5 MHz with the maximum of 18 dBm output power. -
Page 4: Radio Board Connector
Board ID SDA * Connection is available by mounting the corresponding 0 Ohm resistor. (See the schematic of the Radio Board for details.) Figure 2.1. BRD4305E Radio Board Connector Pin Mapping silabs.com | Building a more connected world. Rev. 1.0 | 4... -
Page 5: Radio Board Block Summary
For additional information on the MGM13S12F512GA, refer to the MGM13S data sheet. 3.3.2 LF Crystal Oscillator (LFXO) The BRD4305E Radio Board has a 32.768 kHz crystal mounted. For details regarding the crystal configuration, refer to Application Note "AN0016.1: Oscillator Design Considerations". -
Page 6: Radio Board Connectors
3.3.5 Serial Flash The BRD4305E Radio Board is equipped with an 8 Mbit Macronix MX25R SPI flash that is connected directly to the MGM13S12 to support over-the-air (OTA) updates. For additional information on the pin mapping see the BRD4305E schematic. -
Page 7: Mechanical Details
BRD4305E Reference Manual Mechanical Details 4. Mechanical Details The BRD4305E Radio Board is illustrated in the figures below. Connector RF Output XTAL Selection 40 mm xGM13S Flash 20 mm 33 mm 37.5 mm Figure 4.1. BRD4305E Top View Board Identification 27.3 mm... -
Page 8: Emc Compliance
BRD4305E Reference Manual EMC Compliance 5. EMC Compliance 5.1 Introduction Compliance of the fundamental and harmonic levels of the BRD4305E Radio Board is tested against the following standards: • 2.4 GHz: • ETSI EN 300-328 • FCC 15.247 5.2 EMC Regulations for 2.4 GHz 5.2.1 ETSI EN 300-328 Emission Limits for the 2400-2483.5 MHz Band... -
Page 9: Rf Performance
6.1.1 Conducted Measurements in the 2.4 GHz Band The BRD4305E Radio Board was connected directly to a Spectrum Analyzer through its UFL connector (the was removed and a 0 Ohm resistor was soldered to the position). The supply for the module (VDD) was 3.3 V provided by the mainboard; for details, see the sche- matic of the BRD4305E. -
Page 10: Radiated Power Measurements
6.2.1 Radiated Measurements in the 2.4 GHz Band The supply for the module (VDD) was 3.3 V provided by the mainboard; for details, see the BRD4305E schematic. The transceiver was operated in continuous carrier transmission mode. The output power of the radio was set to 18 dBm based on the conducted measure- ment. -
Page 11: Emc Compliance Recommendations
7.1 Recommendations for 2.4 GHz ETSI EN 300-328 Compliance As shown in the previous section, the power of the fundamental frequency of the BRD4305E Mighty Gecko Radio Board with 18 dBm output is compliant with the 20 dBm limit of the ETSI EN 300-328 regulation in both the conducted and radiated measurements. The harmonic emissions are under the -30 dBm limit with large margin. -
Page 12: Board Revision History
BRD4305E Reference Manual Board Revision History 8. Board Revision History Table 8.1. BRD4305E Radio Board Revisions Radio Board Revision Description Updated module PCB footprint and antenna clearance dimensions. Updated module revision and footprint. Pin 1V8 to WSTK pad conn. option. -
Page 13: Errata
BRD4305E Reference Manual Errata 9. Errata There are no known errata at present. silabs.com | Building a more connected world. Rev. 1.0 | 13... -
Page 14: Document Revision History
BRD4305E Reference Manual Document Revision History 10. Document Revision History Revision 1.00 July, 2018 • Initial document revision. silabs.com | Building a more connected world. Rev. 1.0 | 14... - Page 15 Trademark Information Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®, EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®, ISOmodem®, Micrium, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress®, Zentri, Z-Wave, and others are trademarks or...
