Mechanical & electrical Installation SCS200
Der automatische Torantrieb Modell SCS200 erfüllt die Anforderungen der geltenden
Abschnitte der Normenvorschriften EN300220-3 • EN55014 • EN61000-3 • EN60555,
EN60335-1 • ETS 300 683 • EN60335-1: 2002 • EN60335-2-103: 2003 • EN55014-1:
2000 + A1 + A2 • EN55014-2: 2001 • EN61000-3-2: 2000 • EN61000-3-3: 1995 + A1 • EN
301 489-3, V1.3.1 • EN 300 220-3 V1.1.1 • EN 13241-1
sowie die Bestimmungen und sämtliche Ergänzungen
der EU-Vorschriften ..............................................2006/95/EC, 2004/108/EC, 1999/5/EG
Die automatischen Torantriebe, erfüllen die Bestimmungen der EU-Vorschrift 89/393/EEC
und ihre Ergänzungen, wenn sie gemäß den Anleitungen des Herstellers installiert und
gewartet werden und wenn sie mit einem Tor verwendet werden, das ebenfalls gemäß
Herstelleranleitungen installiert wurde und gewartet wird.
angegebenne Gerät sowie sämtliches im Handbuch aufgeführtes
Zubehör den oben genannten Vorschriften und Normen entspricht.
B.P.Kelkhoff
Manager, Regulatory Affairs
Chamberlain GmbH
D-66793 Saarwellingen
Januar, 2008
for service 06838/907 172
Email: info@chamberlain.de
K o n f o r m i t ä t s e r k l ä r u n g
E i n s c h l u ß e r k l ä r u n g
Die Unterzeichnende erklärt hiermit, dass das vorstehend
www.chamberlain.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCS200 and is the answer not in the manual?

Questions and answers

Related Manuals for Chamberlain SCS200

Summary of Contents for Chamberlain SCS200

  • Page 1 K o n f o r m i t ä t s e r k l ä r u n g Der automatische Torantrieb Modell SCS200 erfüllt die Anforderungen der geltenden Abschnitte der Normenvorschriften EN300220-3 • EN55014 • EN61000-3 • EN60555, EN60335-1 •...
  • Page 2 WARNING / ATTENTION IMPORTANT FITTING AND OPERATING INSTRUCTIONS PLEASE START BY READING THESE IMPORTANT SAFETY RULES • SAVE THESE INSTRUCTIONS This safety alert symbol means "Caution" - failure to comply with such an instruction involves risk of personal injury or damage to property.

  • Page 3: Before You Begin

    AVAILABLE INSTALLATION ACCESSORIES 1. 041ASWG-0482-50 50m roll of installation cable, 6-pole for outdoor use, Laying possible without cable duct with the identical wire colours as motor 2. LA400-JB40E Kit for cable extension of one installation unit. Consists of 12m of cable 6-pole with identical colours, distribution box IP65, cable screw joints and fastening material 3.

  • Page 4: Technical Data

    TECHNICAL DATA: Motor voltage Nominal power Max. power Max. thrust 300daN Spindle travel 300mm Cycles/24h 5-10 Rated operation time 4 min GATE TYPES The location of the motor installation depends on the type of gate. If the gate stop is on the floor the motor should also be installed as low as possible in order for the gate not to be distorted.

  • Page 5: Installation Of Fittings

    INSTALLATION OF FITTINGS First read all of the following 3 sections. It is important for the motor to be installed horizontally. The space between pillar and gate “Tensioning distance” is crucial for later operation. Precision is necessary. If you are not sure , attach fittings to the motor on a trial basis, hold it against the gate and measure for best position.
  • Page 6 TENSIONING DISTANCE The space between the fittings is called tensioning distance. When the gate is closed the trolley on the spindle is in the front and travels during the opening process towards the rear. Note: Adhere to tensioning distance under all circumstances! Dimensions see picture.

  • Page 7: Typical Configuration Of A Unit

    TYPICAL CONFIGURATION OF A UNIT: 1. Motor 2. Control board 3. Photocell (active for closing), max. height 200 mm First photocell. 4. photocell (active for opening and closing), max. height 200 mm Second photocell (optional). 5. Flashing light (optional) Important visual information on the movement of the gate. 6.

  • Page 8: Recommended Procedure

    RECOMMENDED PROCEDURE: Fasten exterior installation box to wall, after previously measuring required distances and establishing correct position of drill- holes (Hardware not included). Baseplate for transformer is already pre-assembled (A). Push fastening clips in designated holes (B) . Push controlboard onto fastening clips (C). Fasten transformer onto baseplate using the large screw and large washer (D).
  • Page 9 TECHNICAL DATA OF MOTOR CONTROL: WIRING OF CONTROL / SUMMARY Voltage 230VAC a) start with still dead 230Volts supply cable on the left side of the box. Transformer 230/24VAC minimum60VA b) Attach cable eye to ground wire. Then connect ground wire to base Output motor 24VDC max.

  • Page 10: Description Of Push Buttons

    To enable the “Automatic Closing” Ω function, the Chamberlain failsafe photocell must be installed. The Chamberlain failsafe system (2-cable system) has small LEDs (light) that can be seen from the outside on both sides to indicate the status of the photocell.

  • Page 11: Key Switch (Optional)

    KEY SWITCH (OPTIONAL) The system can be operated by key switch. It is possible to operate COM PHOTO COM STOP/* only 1 wing or two wings. This depends on how the JUMPERS are 8.2 Ω used (connectors: key symbol and COM) SAFETY EDGE (OPTIONAL) A safety edge working according to the 8.2 kilo ohm principle can be COM PHOTO...
  • Page 12 JUMPERS 1 / 2 Motor RADIO 1 or 2 motors are connected to the control board. FREE: both motors connected LINKED: only one motor connected STOP / 8.2 KOhms Defines if connector STOP / 8.2 KOhms is used for an emergency stop switch or for a safety edge.

  • Page 13: Initial Operation Basic Setting

    INITIAL OPERATION BASIC SETTING Proceed step by step. If you are not sure, start again at the beginning. Take sufficient time to make these settings. 1. Are all components required for operation connected? Motors, photocells, safety contact strip, stop switch. 2.

  • Page 14: Completion Of Installation / Programming

    PROGRAMMING TRAVEL DISTANCES “ADVANCED” NOTE: In this mode P1 must be pressed 9 times. With every time the button is pressed a position (time) is stored. (This allows programming of SOFT-STOP (slow travel) in order to adjust to application. Long or short phases of SOFT-STOP are possible. Both wings must be closed.

  • Page 15: Indication Of The Diagnosis Led

    INDICATION OF THE DIAGNOSIS LED Indication Description Remedy 1x blinking Motor 1 has insufficient connection to control board Green or white cable not wired or badly connected Check terminals precisely. Consider wire lengths 2x blinking Motor 2 has insufficient connection to control board Refer to 1x blinking 3x blinking Limits for motor 2 have not been accepted...
  • Page 16 An appropriate aerial with installation kit can be obtained from Chamberlain as an accessory with the product ref. no. ANT4X-1LM. Not recommended! Change gate! The gate can move in an uncontrolled (dangerous) manner if The gate must follow a slope.

  • Page 17: Ersatzteile / Spareparts

    ERSATZTEILE / SPAREPARTS 41ASWG-554-P3 41ASWG-558 41ASWG-572SA 41ASWG-563 41ASWG-556 41ASWG-14SA 41ASWG-555-G 41ACOM7010 41ASWG-1094SA 41ASWG-560SA 41ASWG-583SA 41ASCS200A 41ASWG-100 41ASWG-564SA 41ACOM24005 41ASWG-604 41A5456B 41ASWG-571 41APEC-8 709456B © Chamberlain GmbH, 2010...
