Summary of Contents for Daewoo DALLM18-320-1
- Page 1 DALLM18-320-1 Lithium lawnmower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SYMBOLS MARKED ON THE PRODUCT ....................2 2. GENERAL SAFETY RULES ........................3 3. GENERAL IDENTIFICATION ........................6 4.TECHNICAL DATA ............................ 7 5.ASSEMBLY ..............................7 6. SAFETY PRECAUTIONS ......................... 9 7. STARTING .............................. 10 8. BLADE ..............................11 9. -
Page 3: Symbols Marked On The Product
WARNING Read and understand all instructions. Save these instructions. Failure to follow all instructions listed below may result in electric shock, re and/or serious injury. The term ‘power tool’ in all of the warnings below refers to your mains-operated (corded) power tool. KNOW YOUR LAWN MOWER Read this manual carefully, observing the recommended safety instructions before, during and after using your lawn mower. -
Page 4: General Safety Rules
2. GENERAL SAFETY RULES The purpose of the safety rules is to attract your attention to possible dangers. The safety symbols and the explanations with them, require your careful attention and understanding. The safety war- nings do not by themselves eliminate any danger. The instruction or warnings they give are not substitutes for proper accident prevention measures. - Page 5 15. Do not mow excessively steep slopes; 16. Use extreme caution when reversing or pulling the lawnmower towards you; 17. Stop the blades if the lawn mower has to be tilted for transportation when crossing surfaces other than grass, and when transporting the lawn mower to and from the area to be mowed; 18.
-
Page 6: General Identification
38. Replace worn or damaged parts for safety; Use only genuine replacement parts and accessories. 39. Be careful during adjustment of the appliance to prevent entrapment of the ngers between moving blades and xed parts of appliance. 40. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly quali ed persons in order to avoid a hazard. -
Page 7: Technical Data
4. TECHNICAL DATA Power: 20 V Drive style: Gears drive Cutting width: 32 cm Speed: 3500 rpm No load running time: 40 Minutes Cutting grass: about 20 Minutes Cutting height: 20/35/50 mm Brack: Electric brack Wheels: front: 125 mm, Rear: 140 mm Grass collection: 35 L Handle angle: adjustable Switch: Double wings for both hands easy operation. - Page 8 5-2 Assembly the grass catcher 1. To t: Raise the rear cover and hitch the grass catcher on rear of mower. (Fig.3A/Fig.3B/Fig.3C/- Fig.3A1/Fig.3B1/Fig.3C1) 2. To remove: grasp and lift the rear cover, remove grass catcher. IMPORTANT: If the position of indicator opening is very dirty, the indicator will not in ate-in this case, clean the position of indicator opening immediately.
-
Page 9: Safety Precautions
Fig. 4A 5-4 Adjustment of handle height The handle of lawn mower is adjustable, it can be suit for different people. (Fig. 5A) When the cutting height is adjust at 20mm, the handle height can be adjust from 84cm to 98cm, 3 position. -
Page 10: Starting
While mowing, stay alert for any foreign objects which may have been missed. (Fig.6A) 2. Never lift the rear of the mower while starting the motor or during normal operation. (Fig.6B) 3. Never place your hands or feel underneath the underpan or into the rear discharge chute while the motor is running. -
Page 11: Blade
wet grass. For effective mowing do not cut wet grass because it tends to stick to the underside of the deck preventing proper mowing of the grass clippings. Cut no more than 1/3 the length of the grass. The recommended cut for mowing is 1/3 the length of the grass. Ground speed will need to be adjusted so the clippings can be dispersed evenly into the lawn. -
Page 12: Maintenance And Care
9. MAINTENANCE AND CARE WARNING! Before performing any Maintenance or cleaning work, Always pull out the mains plug! Do not spray the unit with water. Ingress of water may destroy the Switch-plug combination unit and the electric motor. Clean the unit with a cloth, hand brush, etc. Expert inspection is required, do not make any adjustment by yourself, must contact to customer Service centre: a. -
Page 13: Exploded View
12. EXPLODED VIEW... - Page 14 50. Switch button 1. Buttom cap 51. Switch button spring 2. Tapping screw 52. Top cover of switch box 3. Machine body 53. Swtich button 4. Blade body 54. Switch 5. The bolt 55. Switch the trigger 6. Front wheel cap 56.
-
Page 15: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Lithium Lawnmower Model: DALLM18-320-1 Brand: We GBR Corp. LTD, Room 1002, 10/F., David House, 8-20 Nanking Street, Jordan, Kowloon, Hong Kong, China, declare under our sole responsibility that this product is in conformity and accordan- ce with the following standards and regulations. -
Page 16: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 17 Manufactured under license of Daewoo International Corporation, Korea...
