DEMO MANUAL
DC980A/DC980B
parts list—Dc980B
ITEM QTY REFERENCE
Additional Demo Board Circuit Components
30 0 C6, C17 (OPT)
31 0 C22 (OPT)
32 0 D4, D2 (OPT)
33 0 D5 (OPT)
34 0 Q3, Q4 (OPT)
35 0 Q5, Q6 (OPT)
36 0 R8, R9, R23, R25 (OPT)
37 4 R15, R17, R30, R31
38 4 R32 TO R35
Hardware: For Demo Board Only
39 7 E1, E2, E5, E7,
E12 TO E14
40 6 E4, E6, E8 TO E11
41 7 JP1 TO JP7
42 1 JP8
43 4 MH1 TO MH4
44 7 SH1 TO SH7
12

PART DESCRIPTION

CAP CER 180PF NPO 5% 0603 (OPT)
CAP CER 10nF 25V 10% X7R 0603 (OPT)
DIODE, POWERMITE (OPT)
DIODE, SOT-323 (OPT)
MOSFET Nch DUAL PWR SW 30V SO8 (OPT)
MOSFET Nch DUAL PWR SW 30V SO8 (OPT)
RES USER SELECTABLE 0603 (OPT)
RES 0Ω 0.1W 0603 SMD
RES 10Ω 1/16W 5% 0603
TERM SOLDER TURRET 0.156"H 0.084"L
TERM SOLDER TURRET 0.219" 0.078"L
2MM PIN HEADER 1X3
CONN RECEPT, 2x10 RIGHT ANGLE
STANDOFF, NYLON SNAP-ON
SHUNT FOR 2MM PIN HEADER
MANUFACTURER/PART NUMBER
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
DO NOT INSTALL
VISHAY CRCW0603000ZRT6
PANASONIC ERJ-3EKF10R0V
MILL MAX 2308-2-00-80-00-00-07-0
MILL MAX 2501-2-00-80-00-00-07-0
WÜRTH 620 003 111 21
MILL-MAX 803-93-020-20-001
KEYSTONE 8831
WÜRTH 608 002 134 21
