DEMO MANUAL DC1508B

parts List

item qty RefeReNCe
Required Circuit Components
1 1 U1 (DC1508B-A) or
U2 (DC1508B-B)
2 3 C1, C2, C7
3 8 C3, C4, C5, C6, C8, C9, C10, C11
4 1 J1
5 1 JP1
6 2 JP2, JP3
7 1 LED1
8 4 MH1, MH2, MH3, MH4
9 5 R1, R2, R4, R7, R8
10 1 R3
11 0 R5, R6 (OPTIONAL)
12 3 SH1, SH2, SH3
13 1 S1
14 4 TP1, TP2, TP3, TP4
15 1 U3
6

PaRt DeSCRiPtioN

IC SOCKET, SPRING LOADED, 64-QFN
CAP CER 1µF 16V 10% X7R 0603
CAP CER 0.1µF 16V 10% X7R 0603
CONN HEADER 12POS 2mm STR DL PCB
CONN HEADER 0.100 INCH 1X3POS
CONN HEADER 0.100 INCH 1X4POS
LED GREEN HIGH BRIGHT ESS SMD
STAND-OFF NYLON 1/4" SNAP IN
RES 10.0k 1/10W 1% 0603 SMD
RES 1.3k 1/10W 1% 0603 SMD
RES 10.0k 1/10W 1% 0603 SMD
CONN SHUNT 0.1IN 2POS BLACK
SW SLIDE DPDT 6VDC 0.3A PCMNT
TERM SOLDER TURRET 0.219" 0.078"L
2k I2C SERIAL EEPROM
maNufaCtuReR/PaRt NumBeR
PLASTRONICS: 64QN50S19090-A
MURATA: GRM188R71C105KA12D
MURATA: GRM188R71C104KA01D
FCI: 98414-G06-12ULF
WÜRTH: 613 003 111 21
WÜRTH: 613 004 111 21
PANASONIC: LNJ326W83RA
WÜRTH: 702 931 000
YAGEO: RC0603FR-0710KL
YAGEO: RC0603JR-071K3L
WÜRTH: 609 002 134 21
C&K: JS202011CQN
MILL-MAX: 2501-2-00-80-00-00-07-0
MICROCHIP TECHNOLOGY: 24AA02T-I/OT
