DEMO MANUAL DC1703A

parts List

ITEM QTY REFERENCE
1 3 C1, C2, C3
2 1 C4
3 10 E1-E10
4 5 JP1-JP5
5 1 J1
6 4 R1, R2, R3, R4
7 1 U2
8 5 Shunts as Shown on
Assembly Drawing
9 1 Stencil Top Side Only
U1-A
U1-B
U1-C
U1-D
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from

PART DESCRIPTION

Capacitor, X7R, 0.1µF 16V, 0402
Capacitor, X7R, 0.047µF 16V, 0402
TP , Turret, 0.064"
Jumper, 3-Pin 1 Row 0.079CC
Header, 2×7 Pin, 0.079CC
Resistor., Chip 4.99K 1/16W 1%,0402
IC, Serial EEPROM, TSSOP8
Shunt, 0.079" Center
IC, LTC2655CUF-L16, 4mm × 4mm QFN20UF
IC, LTC2655CUF-H16, 4mm × 4mm QFN20UF
IC, LTC2655CUF-L12, 4mm × 4mm QFN20UF
IC, LTC2655CUF-H12, 4mm × 4mm QFN20UF
MANUFACTURER, PART NUMBER
TDK, C1005X7R1C104K
TDK, C1005X7R1C473K
Mill-Max, 2308-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Molex, 87831-1420
NIC, NRC04F4991TRF
Microchip, 24LC025-I /ST
Samtec, 2SN-BK-G
Stencil, 1703A
Linear Technology, LTC2655CUF-L16
Linear Technology, LTC2655CUF-H16
Linear Technology, LTC2655CUF-L12
Linear Technology, LTC2655CUF-H12
dc1703af
