DEMO MANUAL
DC980A/DC980B
parts list—Dc980a
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 2 C2, C15
3 2 C9, C13
4 1 D1
5 1 R1
6 1 R2
7 13 R3, R7 TO R11, R15,
R16, R19 TO R23
8 3 R4, R5, R6
9 3 R12, R13, R14
10 2 R17, R18
11 1 U1
12 1 U2
Additional Demo Board Circuit Components
13 0 C3, C4, C5, C8, C10 TO
C12, C14 (OPT)
14 0 C6, C7 (OPT)
Hardware: For Demo Board Only
15 1 J1
16 1 JP8
17 7 JP1 TO JP7
18 4 MH1 TO MH4
19 7 SH1 TO SH7
20 18 TP1 TO TP18
10
PART DESCRIPTION
CAP CER 1µF 16V 20% X7R 0603
CAP TANTALUM 10µF 25V 20% 6032
CAP CER 0.1µF 16V 20% X7R 0603
DIODE, SCHOTTKY 200mW SOT-23
RES 10kΩ 0.1W 5% 0603 SMD
RES 100kΩ 0.1W 5% 0603 SMD
RES 0Ω 0.1W 0603 SMD
RES 2kΩ 0.1W 1% 0603 SMD
RES 4.99kΩ 0.1W 1% 0603 SMD
RES 6.34kΩ 0.1W 1% 0603 SMD
IC, 2-CH POWER SUPPLY MONITOR AND MARGIN
CONTROLLER
2
IC, 2k-Bit I C SERIAL EEPROM
OPTION - DO NOT STUFF
OPTION - DO NOT STUFF
2MM PIN HEADER, 2x7
CONN HEADER, 2x10 RIGHT ANGLE
2MM PIN HEADER, 1x3
STANDOFF, NYLON SNAP-ON
SHUNT FOR 2MM PIN HEADER
TERM SOLDER TURRET 0.219" 0.078"L
MANUFACTURER/PART NUMBER
TDK C1608X7R1C105M
AVX TAJW106M025R
AVX 0603YC104MAT
DIODES INC BAT54
VISHAY CRCW0603103JRT6
VISHAY CRCW0603100KFKEA
VISHAY CRCW0603000ZRT6
VISHAY CRCW06032K00JNEA
VISHAY CRCW06034K99JNEA
VISHAY CRCW06036K34JNEA
LINEAR TECHNOLOGY LTC2970CUFD
MICROCHIP 24LC025-I/ST
MOLEX 87831-1420
MILL-MAX 802-10-020-20-001
SAMTEC TMM-103-02-L-S
KEYSTONE 8831
SAMTEC 2SN-BK-G
MILL MAX 2501-2-00-80-00-00-07-0
