Summary of Contents for ARTRAY ARTCAM-536IMX-USB3-T2
- Page 1 Jun 1, 2022 Ver0.90 USB3.0 CMOS CAMERA ARTCAM-536IMX-USB3-T2 INSTRUCTION BOOKLET 8.1M Pixels ARTCAM-536IMX-USB3-T2 Series ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Dimensional Outline ..........................- 11 - 7.1. ARTCAM-536IMX-USB3-T2 ......................- 11 - Spectral sensitivity characteristics (reference value) ..............- 14 - 8.1. ARTCAM-536IMX-USB3-T2（color model） ................- 14 - 8.2. ARTCAM-536IMX-BW-USB3-T2（monochrome model） ............- 14 - 8.3. IR Cut Filter（color model only） ....................- 15 - 8.4. -
Page 3: Attention
1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4. - Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the following link: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf ●We do not guarantee the functions of this product or the descriptions on this manual to be completely adapted to the users’...
-
Page 6: Introduction
2. Introduction ARTCAM-536IMX-USB3-T2 series are USB3.0 CMOS cameras that designed for industrial use. Adopting USB3.0 interface, thus enables direct data transfer to PC without a capture card. 3. Features ⚫ USB3.0 Interface Adopting USB3.0 interface, thus enables direct data transfer to PC without a capture board or a host adapter card. -
Page 7: Connections
5. Connections Please connect the camera and the PC by using the attached USB3.0 cable. Camera’s power is supplied from USB Bus Power. - 7 -... -
Page 8: Specification
6. Specification 6.1. Specifications Items color monochrome ARTCAM-536IMX-BW-USB3-T2 Model ARTCAM-536IMX-USB3-T2 ARTCAM-536IMX-NIR-USB3-T2 Sensor Type CMOS Image Sensor Model Number IMX536-AAQJ-C IMX536-AAMJ-C Active Pixels 2856(H) x 2848(V) 7.82（H）×7.80（V）mm Active Image Size 2/3 Inch Scanning mode Progressive Scan Pixel Size 2.74(H)×2.74(V)μm Shutter Global Shutter... -
Page 9: Camera's Functions
6.2. Camera’s functions 6.2.1. Shutter Speed You can set the exposure time (electronic shutter speed) of the camera. (Supports 0.1 to 26 milliseconds on software *) * The setting resolution on the software is in units of 100 μs (0.1 milliseconds), and the closest value is set by calculation in the software. -
Page 10: Mirror Reversal
6.2.3. Mirror Reversal The sensor utilized in this camera provides horizontal and vertical mirror reversal function. In a normal position (of no avail to both horizontal reversal and vertical reversal), the lower left corner of the direction in which the front of the camera is oriented is the origin (0, 0). When horizontally or vertically reversed, the Bayer setting of the software will be automatically converted. -
Page 11: Dimensional Outline
7. Dimensional Outline 7.1. ARTCAM-536IMX-USB3-T2 Drawing of the base without a tripod mount - 11 -... - Page 12 Illustrations of the relationship between the Mount and the Sensor surface The height of the light receiving surface when the PCB Board pasted is mounted - 12 -...
- Page 13 Position Relationship Diagram between the sensor package and the light receiving surface H = 3.45[um] * 2448 = 8445.6 [um] V = 3.45[um] * 2048 = 7065.6 [um] Field of Vision: Lens versus Sensor（reference value） ※The ratios of sensor size (diagonal) to lens size in the above illustrations are as follows: 1/2 inch = φ8mm, 2/3 inch = φ11mm, 1 inch = 15.8mm Please note that the actual field of view varies depending on different lens.
-
Page 14: Spectral Sensitivity Characteristics (Reference Value)
8. Spectral sensitivity characteristics (reference value) 8.1. ARTCAM-536IMX-USB3-T2（color model） 8.2. ARTCAM-536IMX-BW-USB3-T2（monochrome model） - 14 -... -
Page 15: Ir Cut Filter（Color Model Only
8.3. IR Cut Filter（color model only） Glass Material: White Board (B270) Reference refractive index 1.52 Thickness: 1.00mm (within a tolerance of ±0.1mm) 8.4. Characteristic of Visible Light Cut Filter Model Name: R70 Reference refractive index 1.546 Thickness: 2.50mm - 15 -... -
Page 16: System Requirements
9. System Requirements 9.1. Recommended System Requirements ●Host Controller This camera is applicable to USB 3.0. Connecting to USB 2.0 host controller may cause low-speed or failure to function properly. ●CPU computer architecture The driver of this camera is applicable to “x86”... - Page 17 ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us URL: www.artray. us - 17 -...
