USB3.0 CMOS CAMERA
ARTCAM-MI-USB3 Series
INSTRUCTION BOOKLET
5.0 M pixels
9.0 M pixels
10.0 M pixels
14.0 M pixels
ARTRAY CO., LTD.
ARTCAM-500MI-USB3 Series
ARTCAM-900MI-USB3 Series
ARTCAM-1000MI-USB3 Series
ARTCAM-1400MI-USB3 Series
July 12, 2012
Ver1.10

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARTCAM-MI-USB3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ARTRAY ARTCAM-MI-USB3 Series

  • Page 1 July 12, 2012 Ver1.10 USB3.0 CMOS CAMERA ARTCAM-MI-USB3 Series INSTRUCTION BOOKLET 5.0 M pixels ARTCAM-500MI-USB3 Series 9.0 M pixels ARTCAM-900MI-USB3 Series 10.0 M pixels ARTCAM-1000MI-USB3 Series 14.0 M pixels ARTCAM-1400MI-USB3 Series ARTRAY CO., LTD.
  • Page 2: Table Of Contents

    Contents 1. Attention ··············································· 3 2. Introduction ··········································· 6 3. Main Features ······································· 6 4. The Product ·········································· 7 5. Connect the Camera ······························ 8 6. Specifications ········································ 9 7. External Dimensions ······························ 12 8. System Requirements ···························· 13 - 2 -...
  • Page 3: Attention

    1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide an replacement. 4.
  • Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
  • Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below : Hardware Warranty : http : //www.artray.us/download/artray_warranty.pdf - 5 -...
  • Page 6: Introduction

    2. Introduction ARTCAM-MI-USB3 Series is CMOS cameras for industrial use. This series adopt USB3.0 interface, so the data can be delivered to PC directly without a capture board. 3. Main Features ・High Resolution, High Frame Rate We provide high speed USB3.0 CMOS cameras of a wide range of resolutions from 5 mega pixels to 14 mega pixels.
  • Page 7: The Product

    4. The Product 1) Camera 2) USB3.0 cable TYPE A-B connector 2m 3) Introduction Booklet 4) Viewer software/Device Driver CD <Options> 1) C Mount lens 2) 2 Measurement & Filing Software [ART-MEASURE] 3) Recording Software [ART-REC] 4) Software Development Kit [ARTCCM-SDK] - 7 -...
  • Page 8: Connect The Camera

    5. Connect the Camera 5-1 How to connect a camera 5-2 Shutter Speed Shutter speed can be changed on the standard viewer software ART-Viewer. The shutter speed is set directly on the sensor register, so please refer to the following formulas for the real exposure time.
  • Page 9: Specifications

    6. Specifications 6-1 Color Model(1) ARTCAM-500MI-USB3 ARTCAM-900MI-USB3 ARTCAM-1000MI-USB3 ARTCAM-1400MI-USB3 Sensor Type CMOS Color Image Sensor Active Pixels 2592(H)×1944(V) 3488(H)×2616(V) 3840(H)×2768(V) 4384(H)×3288(V) Active Imager 5.70(H)×4.28(V)mm 6.10(H)×4.58(V)mm 6.41(H)×4.59(V)mm 6.14(H)×4.60(V)mm Size 1/2.5” 1/2.3” 1/2.3” 1/2.3” Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm 1.75(H)×1.75(V)μm 1.67(H)×1.67(V)μm 1.4(H)×1.4(V)μm Shutter Type...
  • Page 10 6-2 Monochrome Model ARTCAM-500MI-BW-USB3 Sensor Type CMOS Monochrome Image Sensor Active Pixels 2592(H)×1944(V) Active Imager 5.70(H)×4.28(V)mm 1/2.5” Size Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm Shutter Type Rolling Shutter Frame Rate 13.9fps Shutter Speed 1/34808~0.543s Interface USB3.0 Bulk Transfer Synchronization Internal Synchronization System Lens Mount...
  • Page 11 6-3 NIR model ARTCAM-500MI-NIR-USB3 Sensor Type CMOS Monochrome Image Sensor Active Pixels 2592(H)×1944(V) Active Imager 5.70(H)×4.28(V)mm 1/2.5” Size Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm Shutter Type Rolling Shutter Frame Rate 13.9fps Shutter Speed 1/34808~0.543s Interface USB3.0 Bulk Transfer Synchronization Internal Synchronization System Lens Mount...
  • Page 12: External Dimensions

    7. External Dimensions 7-1 C-MOUNT, CASED, USB CABLE TYPE ARTCAM-500MI-USB3/500MI-BW-USB3 /500MI-NIR-USB3 ARTCAM-900MI-USB3 ARTCAM-1000MI-USB3 ARTCAM-1400MI-USB3 - 12 -...
  • Page 13: System Requirements

    *For the recommended extension cable, please contact our sales department. (TEL : +81-3389-5488) ARTRAY CO., LTD. 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel : +81-3-3389-5488 Fax : +81-3-3389-5486 Email : sales@artray.us URL : www.artray. us - 13 -...
