USB2.0 CMOS CAMERAS SMALL TYPE

INSTRUCTION BOOKLET

0.36M pixels

1.3M pixels

2.0M pixels

3.0M pixels

5.0M pixels

9.0M pixels

10.0M pixels

ARTCAM-SS Series

ARTCAM-036SS Series

ARTCAM-130SS Series

ARTCAM-D131SS Series

ARTCAM-300SS Series

ARTCAM-500SS Series

ARTCAM-900SS Series

ARTCAM-1000SS Series

ARTRAY CO., LTD.

August 30, 2012

Ver1.01

Table of Contents

Need help?

Do you have a question about the ARTCAM-SS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTRAY ARTCAM-SS Series

Page 1 August 30, 2012 Ver1.01 USB2.0 CMOS CAMERAS SMALL TYPE ARTCAM-SS Series INSTRUCTION BOOKLET 0.36M pixels ARTCAM-036SS Series 1.3M pixels ARTCAM-130SS Series 2.0M pixels ARTCAM-D131SS Series 3.0M pixels ARTCAM-300SS Series 5.0M pixels ARTCAM-500SS Series 9.0M pixels ARTCAM-900SS Series 10.0M pixels ARTCAM-1000SS Series...
Page 2 - 2 -...
Page 3: Table Of Contents
Contents 1. Attention………………………………….3 2. Introduction………………………………6 3. Main Features……………………………6 4. The Product………………………………7 5. Connect the Camera…………………….8 6. Specifications…………………………….9 7. External Dimensions…………………….13 8. Recommended PC………………………17 - 3 -...
Page 4: Attention
1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4.
Page 5 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
Page 6 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below : Hardware Warranty : http : //www.artray.us/download/artray_warranty.pdf - 6 -...
Page 7: Introduction
We provide high speed CMOS cameras of a wide range of resolutions from 0.36 mega pixels to 10 mega pixels. ・USB2.0 Interface Artray SS series adopts USB2.0 interface, so the data can be delivered to PC directly and no capture board is needed. ・Small and Light Artray SS series is available with C-mount.
Page 8: The Product
・Software Development Kit(Optional) For customer who prefers to create their own image processing software or use our camera with other applications, we provide SDK upon requests. 4. The Product 1) Camera 2) USB Cable SS series : One end of the cable integrated to the camera, 1.8m approx. SSK series : TYPE A-mini B connector, 1m approx.
Page 9: Connect The Camera
5. Connect the Camera 5-1 How to connect a camera 5-2 Shutter Speed Shutter speed can be changed on the standard viewer software ART-Viewer. The shutter speed is set directly on the sensor register, so please refer to the following formulas for the real exposure time.
Page 10: Specifications
6. Specifications 6-1 Color Model(1) ARTCAM- ARTCAM- ARTCAM- ARTCAM- 036SS 130SS D131SS 300SS 036SSK 130SSK D131SSK 300SSK 036SS-OP 130SS-OP D131SS-OP 300SS-OP 036SS-OP-CM 130SS-OP-CM D131SS-OP-CM 300SS-OP-CM Sensor Type CMOS Color Image Sensor Active Pixels 752(H)×480(V) 1280(H)×1024(V) 1600(H)×1200(V) 2048H)×1536(V) Active Imager 4.51(H)×2.88(V)mm 6.66(H)×5.32(V)mm 4.73(H)×3.52(V)mm 6.55(H)×4.92(V)mm...
Page 11 6-2 Color Model (2) ARTCAM- ARTCAM- ARTCAM- 500SS 900SS 1000SS 500SSK 900SSK 1000SSK 500SS-OP 900SS-OP 1000SS-OP 500SS-OP-CM 900SS-OP-CM 1000SS-OP-CM Sensor Type CMOS Color Image Sensor Active Pixels 2592(H)×1944(V) 3488(H)×2616(V) 3840(H)×2768(V) Active Imager 5.70(H)×4.28(V)mm 6.10(H)×4.58(V)mm 6.41(H)×4.59(V)mm 1/2.5” 1/2.3” 1/2.3” Size Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm...
Page 12 6-3 Monochrome Model ARTCAM- ARTCAM- ARTCAM- 036SS-BW 130SS-BW 500SS-BW 036SSK-BW 130SSK-BW 500SSK-BW 036SS-BW-OP 130SS-BW-OP 500SS-BW-OP 036SS-BW-OP-CM 130SS- BW-OP-CM 500SS-BW-OP-CM Sensor Type CMOS Monochrome Image Sensor Active Pixels 752(H)×480(V) 1280 (H)×1024(V) 2592(H)×1944(V) Active Imager 4.51(H)×2.88(V)mm 6.66(H)×5.32(V)mm 5.70(H)×4.28(V)mm 1/3” 1/2” 1/2.5” Size Scan Mode Progressive Scan Pixel Size...
Page 13 6-4 NIR Model ARTCAM- ARTCAM- ARTCAM- 036SS-NIR 130SS-NIR 500SS-NIR 036SSK-NIR 130SSK-NIR 500SSK-NIR 036SS-NIR-OP 130SS-NIR-OP 500SS-NIR-OP 036SS-NIR-OP-CM 130SS- NIR-OP-CM 500SS-NIR-OP-CM Sensor Type CMOS Monochrome Image Sensor Active Pixels 752(H)×480(V) 1280 (H)×1024(V) 2592(H)×1944(V) Active Imager 4.51(H)×2.88(V)mm 6.66(H)×5.32(V)mm 5.70(H)×4.28(V)mm 1/3” 1/2” 1/2.5” Size Scan Mode Progressive Scan Pixel Size...
Page 14: External Dimensions
7. External Dimensions 7-1 C-MOUNT, CASED, USB CABLE TYPE ARTCAM-036SS/036SS-BW/036SS-NIR ARTCAM-130SS/130SS-BW/130SS-NIR ARTCAM-D131SS ARTCAM-300SS ARTCAM-500SS/500SS-BW/500SS-NIR ARTCAM-900SS ARTCAM-1000SS - 14 -...
Page 15 7-2 C MOUNT, CASED, USB MINI B CONNECTOR TYPE ARTCAM-036SSK/036SSK-BW/036SSK-NIR ARTCAM-130SSK/130SSK-BW/130SSK-NIR ARTCAM-D131SSK ARTCAM-300SSK ARTCAM-500SSK/500SSK-BW/500SSK-NIR ARTCAM-900SSK ARTCAM-1000SSK - 15 -...
Page 16 7-3 BOARD LENS, BOARD TYPE ARTCAM-036SS-OP/036SS-BW-OP/036SS-NIR-OP ARTCAM-130SS-OP/130SS-BW-OP/130SS-NIR-OP ARTCAM-D131SS-OP ARTCAM-300SS-OP ARTCAM-500SS-OP/500SS-BW-OP/500SS-NIR-OP ARTCAM-900SS-OP ARTCAM-1000SS-OP - 16 -...
Page 17 7-4 C-MOUNT, BOARD TYPE ARTCAM-036SS-OP-CM/036SS-BW-OP-CM/036SS-NIR-OP-CM ARTCAM-130SS-OP-CM/130SS-BW-OP-CM/130SS-NIR-OP-CM ARTCAM-D131SS-OP-CM ARTCAM-300SS-OP-CM ARTCAM-500SS-OP-CM/500SS-BW-OP-CM/500SS-NIR-OP-CM ARTCAM-900SS-OP-CM ARTCAM-1000SS-OP-CM *The length of this spacer varies by model Model Spacer (length) 036SS-OP-CM 2.3mm 036SS-BW-OP-CM 036SS-NIR-OP-CM 3.2mm 130SS-OP-CM／130SS-BW-OP-CM 2.8mm 130SS-NIR-OP-CM D131SS-OP-CM／300SS-OP-CM 500SS-OP-CM／500SS-BW-OP-CM 2.4mm 900SS-OP-CM／1000SS-OP-CM 500SS-NIR-OP-CM 3.6mm - 17 -...
Page 18: Recommended Pc
Especially if the PC adopts a Cypress control chip, it may not recognize the later connected bulk transfer device if the device is connected when the Artray camera is in function. This issue is hard to be solved because the problem is on the lower firmware of the control chip and the PC bios.
