ARTRAY ARTCAM-2020UV-CL Instruction Booklet

Camera link uv cmos camera
Hide thumbs Also See for ARTCAM-2020UV-CL:
Table of Contents

Advertisement

Quick Links

Download this manual
November 13, 2020
Ver1.02
Camera Link UV CMOS Camera
ARTCAM-2020UV-CL
INSTRUCTION BOOKLET
4.00 M Pixels
ARTCAM-2020UV-CL
ARTRAY CO., LTD.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTCAM-2020UV-CL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ARTRAY ARTCAM-2020UV-CL

Summary of Contents for ARTRAY ARTCAM-2020UV-CL

  • Page 1 November 13, 2020 Ver1.02 Camera Link UV CMOS Camera ARTCAM-2020UV-CL INSTRUCTION BOOKLET 4.00 M Pixels ARTCAM-2020UV-CL ARTRAY CO., LTD. - 1 -...

  • Page 2: Table Of Contents

    Camera’s Functions.............................- 11 - 6.2.1. Shutter Speed ..............................- 11 - 6.2.2. External Trigger Function..........................- 11 - Spectral Sensitivity Characteristics..........................- 13 - 7.1. ARTCAM-2020UV-CL............................- 13 - 7.2. UV Bandpass Filter（U340）(Optional）......................- 13 - Recommended System Requirements........................- 14 - - 2 -...

  • Page 3: Attention

    1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4.
  • Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
  • Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf - 5 -...

  • Page 6: Introduction

    2. Introduction ARTCAM-2020UV-CL is a series of ultraviolet cameras with high sensitivity to the wavelength band of 200 nm to 1100 3. Main Features  UV Detection with High Sensitivity The CMOS sensor can detect radiation invisible to human eyes and CMOS cameras in the wavelength range between 200 nm to 1100 nm band.

  • Page 7: Setup

    5. Setup 5.1. Connecting Method (an example) 5.1.1. When using on a desktop PC MDR-26pin PIXCI-EB1 5.1.2. When using on a notebook PC SDR-26pin PIXCI-EB1-34 *There is an unique port of CameraLink channel used since this camera operates with CameraLink - Base Configuration. For the connector of this camera is SDR-26pin, please use the supported cable.

  • Page 8: Specifications

    6. Specifications 6.1. Camera Specification 6.1.1. Camera specification list Items Image pickup device Gpixel 4.0M pixels CMOS Sensor GSENSE2020BSI Number of effective pixels 2058(W) x 2056(H) Number of output pixels 2048(W) x 2048(H) Pixel Size 6.5(H) [µm] × 6.5(V) [µm] 13.3(H)×13.3(V)[mm] Imaging area (Diagonal 18.809[mm], Approx.1.2 inch)

  • Page 9: Dimensional Outline

    6.1.2. Dimensional Outline HR10A-7R-6S(73)(HIROSE) Drawing of the base without a tripod mount - 9 -...

  • Page 10: Schematic Diagram Of The Sensor

    6.1.3. Schematic Diagram of the Sensor - 10 -...

  • Page 11: Camera's Functions

    6.2. Camera’s Functions 6.2.1. Shutter Speed The exposure time (electronic shutter speed) of the camera can be set. The exposure time can be calculated by the following formula: Exposure time = the setting value of the shutter speed * 1 H period = 560(Minimum) * 1PCLK ＝...
  • Page 12 Details of trigger timing Item Items Required Time Numbers Effective Trigger Input Pulse >10μsec. Time required from the starting of the External <1μsec. Trigger to the starting of the Internal Trigger Signals (may delay caused by the photocoupler) Time required from the starting of the Internal <1μsec.

  • Page 13: Spectral Sensitivity Characteristics

    7.1. ARTCAM-2020UV-CL 7.2. UV Bandpass Filter（U340）(Optional） ARTCAM-2020UV-CL is possible to choose to install an additional filter U340, which can absorb visible wavelengths and only allow ultraviolet wavelengths to pass. Please refer to the following Spectral sensitivity line chart for detail.

  • Page 14: Recommended System Requirements

    Please confirm with us if you are using different grabber. ●PC Please confirm the recommended requirement of the Camera Link frame grabber you are using. ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us...
