- Page 1 December 14, 2022 Ver1.02 USB3.0 CMOS CAMERA ARTCAM-MI-USB3-T2 Series INSTRUCTION BOOKLET 5.0 M Pixels ARTCAM-500MI-USB3-T2 Series 10.0 M Pixels ARTCAM-1000MI-USB3-T2 Series 14.0 M Pixels ARTCAM-1400MI-USB3 -T2 Series ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Contents Attention ..............................- 3 - Introduction .............................. - 6 - Features ..............................- 6 - The Product .............................. - 8 - Connect the Camera ..........................- 8 - 5.1. How to connect a camera ....................... - 8 - 5.2. Shutter Speed ........................... -
Page 3: Attention
1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4. - Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the following link: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf ●We do not guarantee the functions of this product or the descriptions on this manual to be completely adapted to the users’...
-
Page 6: Introduction
2. Introduction ARTCAM-MI-USB3-T2 Series is CMOS cameras designed for industrial use. Adopting USB3.0 enable direct data transfer to PC without a capture board. 3. Main Features ⚫ High Resolution, High Frame Rate Realize High speed of USB3.0 interface, wide range of resolutions from 5 mega pixels to 14 mega pixels. - Page 7 Camera image acquisition and camera control are possible with other applications is included as standard. You can also download it from the website below. http://www.artray.us/download_sdk.html ⚫ 2D Measurement & Filing Software(Optional) Useful 2D measuring functions are available with the optional 2D Measuring & Filing Software - ART-MEASURE.
-
Page 8: The Product
4. The Product 1) Camera 2) USB3.0 Cable A to Micro B connector 3m (with locking screws) 3) Introduction Booklet 4) Viewer software/Device Driver CD 5) Software Development Kit [ARTCCM-SDK] <Options> 1) C Mount lens 2) 2 Measurement & Filing Software [ART-MEASURE] 5. -
Page 9: Specifications
6. Specifications 6.1. Color Model ARTCAM-500MI-USB3-T2 ARTCAM-1000MI-USB3-T2 ARTCAM-1400MI-USB3-T2 Sensor Type CMOS Color Image Sensor Active Pixels 2592(H)×1944(V) 3856(H)×2764(V) 4068(H)×3288(V) Active Imager 5.70(H)×4.28(V)mm 6.41(H)×4.59(V)mm 6.45(H)×4.60(V)mm Size 1/2.5” 1/2.3” 1/2.3” Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm 1.67(H)×1.67(V)μm 1.4(H)×1.4(V)μm Shutter Type Rolling Shutter Color Filter Array RGB Bayer Pattern Frame Rate... -
Page 10: Monochrome Model
6.2. Monochrome Model ARTCAM-500MI-BW-USB3-T2 ARTCAM-1000MI-BW-USB3-T2 Sensor Type CMOS Monochrome Image Sensor Active Pixels 2592(H)×1944(V) 3856(H)×2764(V) Active Imager 5.70(H)×4.28(V)mm 1/2.5” 6.41(H)×4.59(V)mm 1/2.3” Size Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm 1.67(H)×1.67(V)μm Shutter Type Rolling Shutter Frame Rate 13.9fps 6fps Shutter Speed 1/10000～2.0s 1/10000～2.0s Interface... -
Page 11: Nir Model
6.3. NIR model ARTCAM-500MI-NIR-USB3-T2 ARTCAM-1000MI-NIR-USB3-T2 Sensor Type CMOS Monochrome Image Sensor Active Pixels 2592(H)×1944(V) 3856(H)×2764(V) Active Imager 5.70(H)×4.28(V)mm 1/2.5” 6.41(H)×4.59(V)mm 1/2.3” Size Scan Mode Progressive Scan Pixel Size 2.2(H)×2.2(V)μm 1.67(H)×1.67(V)μm Shutter Type Rolling Shutter Frame Rate 13.9fps 6fps Shutter Speed 1/10000～2.0s 1/10000～2.0s Interface... -
Page 12: External Dimensions
External Dimensions 7.1. C-MOUNT, CASED CAMERA ARTCAM-500MI-USB3-T2/ 500MI-BW-USB3-T2 / 500MI-NIR-USB3-T2 ARTCAM-1000MI-USB3-T2/ 1000MI-BW-USB3-T2/ 1000MI-NIR-USB3-T2 ARTCAM-1400MI-USB3-T2 - 12 -... -
Page 13: Spectral Sensitivity Characteristics
8. Spectral sensitivity characteristics 8.1. ARTCAM-500MI-USB3-T2 series(Color Model) 8.2. ARTCAM-500MI-BW-USB3-T2 series(Monochrome Model) - 13 -... -
Page 14: Artcam-1000Mi-Usb3-T2 Series(Color Model)
8.3. ARTCAM-1000MI-USB3-T2 series(Color Model) 8.4. ARTCAM-1000MI-BW-USB3-T2 series(Monochrome Model) - 14 -... -
Page 15: Artcam-1400Mi-Usb3-T2 Series(Color Model)
8.5. ARTCAM-1400MI-USB3-T2 series(Color Model) - 15 -... -
Page 16: System Requirements
9. System Requirements 9.1. Recommended System Requirements ●Host Controller This camera is applicable to USB 3.0. Connecting to USB 2.0 host controller may cause low-speed or failure to function properly. ●CPU computer architecture The driver of this camera is applicable to “x86”... - Page 17 ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us URL: www.artray. us - 17 -...
