1-2.9 AC'97 Audio Codec on board

AC'97 Audio Codec 2.2 compliant on board
• Supporting up to 6 channels of PCM audio output
• 6 channel audio consists of Front Left, Front Right, Back Left, Back
Right, Center and Woofer for complete surrround sound effect
• AC'97 Audio Codec Driver enclosed in Support CD for user 's
installation.

1-2.10 LAN on board (85ERV-L only)

Fast Ethernet Controller integrated in VT8235 and PHY VIA VT6103:
• Supporting 10/100Mb Fast Ethernet Base T LAN
• Supporting Wake On LAN through on-board WOL1 connector
• LAN Driver enclosed in Support CD for user's installation.

1-2.11 Hardware Monitor on board

• Hardware Monitor integrated in Super I/O IT8705F, providing moni-
toring and alarm for flexible desktop management of hardware voltage,
temperatures and fan speeds.
• Utility Software SmartGuardian for displaying Monitoring status is
enclosed in Support CD for user's installation.

1-2.12 6-channel Sound Output Support (optional)

• This series is designed with an optional 6-channel Audio-out connec-
tor "Audio1". If this option is chosen, it will provide 3 additional audio-
out ports for the 6-channel sound.

1-2.13 Form Factor

• ATX form factor, ATX power supply, version 2.03 compliant, supported
by one Main Power Connector, one +12V Power Connector and one
Peripheral Power Connector
• Mainboard size: 305mm x 220mm
Chapter 1 Specification
13
