85ERV / 85ERV-L
2-9.4 Audio 1: 6-channel Sound Output Connector (optional)
This series is designed with an optional 6-channel Audio-out connector
"Audio1". If this option is chosen, it will provide 3 additional audio-out
ports for the 6-channel sound.
6-channel Audio-out Pin Assignment
Pin 1 LFE-out
Pin 3 Center-out
Pin 5 Surround-out-R
Pin 7 Surround-out-L
Pin 9 Jack-detect
Pin11 SPDIFI
Pin13 SPDIFO
2
1
2-9.5 Chassis Panel Connectors
A.
B.
E.
F.
A : PS/2 MOUSE PORT
B : Rj45 (85ERV-L only)
C : LPT1 PORT
D : GAME/MIDI PORT
E : PS/2 KEYBOARD PORT
F : USB 1 PORT (Bottom)
F : USB 0 (Middle)
G : COM1 PORT
Pin 2 Gnd
Pin 4 Gnd
Pin 6 Gnd
Pin 8 Gnd
Pin10 (Void)
Pin12 Gnd
Pin14 Gnd
14
13
C.
G.
H.
H : COM2 PORT
I
J : LINE IN /
K : MICROPHONE INPUT /
30
RT1
PS/2 Mouse
(on top)
PS/2 K/B
(underside)
Rj 45
(on top)
USB0 (middle)
USB1 (underside)
Main Power
Connector
VIA
P4x400
Peripheral Power
AGP 4X/8X
Connector
VIA VT6103
PCI 1
PHY (LAN Controller)
1
CD1
PCI 2
VIA
PCI 3
AC'97
Codec
VT8235
Audio Codec
PCI 4
1
JBAT1
PCI 5
PCI 6
AUDIO1
14
SCR1
10
10
JUSB1
WOL1
JUSB2
1
1
1
1
1
D.
I.
J.
K.
: LINE Out /
Front SPEAKER OUT
Rear Speaker In
Center Subwoofer Out
1
JP1
RT2
1
FAN3
IT8705F
LPC I/O
FLASH BIOS
14
