Vicon VN-755IPV5 Installation & Operation Manual

Ip cameras/servers

Advertisement

Quick Links

XX156-03-00
VN-755IPV5 AND VN-755IPV5-C
IP CAMERAS/SERVERS
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not
be used for this purpose.
Warning: To prevent fire or shock hazard, do not expose the unit to rain
or moisture.
Copyright © 2008 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
ViconNet and Kollector are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NY 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288)
TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44 (0) 1489-566300
WEB: www.vicon-cctv.com
Vicon part number 8009-8156-03-00
Rev 908 Section 1/3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VN-755IPV5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon VN-755IPV5

  • Page 1 VN-755IPV5 AND VN-755IPV5-C IP CAMERAS/SERVERS Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
  • Page 3: Fcc Notice

    FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.
  • Page 4 8. Accessories - Do not place the unit on an unstable surface is not incorporated in the equipment or when the plug on the to avoid falling. Use only UL Listed Vicon recommended mounting power supply is intended to serve as the disconnect device, accessories.
  • Page 5: Packing List

    1. Iris lens connector plug for DC drive – 1 pc 2. Dust protective cap – 1 pc 3. Ferrite clamp – 2 pc 4. Manual – 1 pc 5. Installation CDs – 2 pc XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 6: Connectors And Controls

    ViconNet network (using Version 5 software). When used as a single-channel camera (with no analog cameras connected), the VN-755IPV5 delivers up to 30 fps. With the addition of 1-3 external connected, there is a maximum of 15 fps total.
  • Page 7: Ethernet (Network Port)

    Recommendations, prepare a 2-conductor type cable by stripping the ends back for use. Connect each sensor wire to the required sensor connection(s) in the Telco box (for example, SENS 1). Connect the other sensor wire to the GND connector. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 8 3. Connect the other end of this cable to the appropriate microphone. NOTE: The microphone should be a 0 dbm output, 32 KHz bandwidth, 600 ohm impedance and 2 V RMS (1 V p-p) output dynamic type. Inline Resistor Telco Box Connections XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 9: Network Led

    This function may not operate properly if the object is too small compared to the area of the background. This function can be used with either the linear shutter (EE/ELC mode) or an autoiris lens (AI lens/ALC mode). XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 10 4. Fixed iris or manual iris lenses may be used with the linear shutter (EE/ELC mode) when the scene brightness varies over a limited range. 5. Do not use the EE/ELC mode when an autoiris lens is installed. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 11 2. If camera A's adjustment range is insufficient, adjust camera B's V-phase control push button in the opposite direction to camera A until they are in phase. 3. If these adjustments do not bring vertical sync from both cameras in phase, recheck the polarity of the power supply connections. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 12: Back Focus Adjustment

    Backfocusing Zoom Lenses 1. Install a lens and connect the camera to a monitor and power supply. If the lens is motorized, it must also be connected to a lens control. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 13 Remove this cap before installing the lens. Do not handle or leave the camera with cap off. 14. CAMERA MOUNTING HOLE There are two mounting holes provided, one each on the top and bottom of the camera. 15. AUTOIRIS LENS CONNECTOR FOR DC DRIVE LENS XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 14: Viconnet Configuration

    Kollector Elite Recorders and ViconNet Workstations can be used for live viewing and recording of network- streamed video. A network can be as simple as a single VN-755IPV5 4-Channel Camera connected to a ViconNet Workstation or can be complex with the addition of several networks interconnected via WAN.
  • Page 15 XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 16: Configuring The Network Settings

    (By default, the setup files will be installed to C:\VUG.) In Password file status, the number of passwords stored is displayed. Load a list of passwords is intended for very large sites only. Contact Technical Support to use this feature. Setup XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 17 XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 18: Select Tab

    Note: You MUST click the Select button to add the unit to the list; verify that it is added to the list. 5. The selected unit appears on the Selected unit section on the top of the screen and settings can be changed. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 19: Install Tab

    Note: Verify all IP addressing parameters with your IT administrator. Unit Install TAB The Install TAB allows the user to install/upgrade newer versions. Choose the correct version and click Install to send to the selected unit. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 20: Advanced Tab

    Loading of application is disabled. The Disable load button allows the pausing of the application load in case of software issues while still permitting communication via VNSetup; the Enable load button resumes the application load. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 21: Custom Tab

    From the workstation desktop, run the ViconNet application. After logging in, open the site setup selection window. Select the IP dome camera setup. Open the Network Setup and Site Name setup window. Network Settings window will display. See Figure below. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 22: Viconnet (Ip/Lan) Version Operation

    3. PTZ control can be performed from any networked workstation, recorder or server. Authorization for PTZ can be assigned to specific operator levels. Refer to the ViconNet workstation manual XX113-3X for complete information on operation. A copy of the manual can be found on the CD included. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 23: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
  • Page 24: Coaxial Cable Recommendations

    Let the required picture quality and cable distance provide a guide in choosing the best cable type. For cables other than the approved Vicon types below, contact the manufacturers listed below. Note that “BC” refers to bare copper and “TC” refers to tinned copper.
  • Page 25: Twisted-Pair Cable

    Twisted-Pair Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use a pure copper stranded conductor with or without a tin-plating to obtain a low DC resistance. Do not use cable with either steel or aluminum stranded conductor because they do not transfer signals effectively for long distances.
  • Page 26: Network Cable

    Network Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use pure copper stranded conductors to obtain a low DC resistance. The preferred insulation and cable jacket is Polyvinyl chloride (PVC).
  • Page 27: Technical Information

    - 24 hours normal activity with 50% detected movement over time, Normal compression and Quality Q5 (320 x 240 pixels NTSC, 384 x 288 pixels PAL) - Recording durations may vary based on actual scene activity. XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 28: Controls And Connectors

    Network: RJ-45 CAT 5 (rear). See rear Panel diagram. Wire Size (AWG) Maximum Distance Annealed ft (m) Copper Wire 240 (73) 375 (114) 600 (183) 960 (293) 1500 (457) Table 2: Maximum Power Cable Distances XX156-03-00 Rev 908 VN-755IPV5 Camera...
  • Page 29 Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion.
  • Page 30 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Germany vin-videotronic infosystems gmbh...
