XX156-00-01
VN-755IP AND VN-755IP-C
IP CAMERAS/SERVERS
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not
be used for this purpose.
Warning: To prevent fire or shock hazard, do not expose the unit to rain
or moisture.
Copyright © 2005 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NY 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288)
TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44 (0) 1489-566300
WEB: www.vicon-cctv.com
Vicon part number 8009-8156-00-01
Rev 705
Section 1/3
Advertisement
Table of Contents
Related Manuals for Vicon VN-755IP
Summary of Contents for Vicon VN-755IP
- Page 1 VN-755IP AND VN-755IP-C IP CAMERAS/SERVERS Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 3: Fcc Notice
FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception. -
Page 5: Important Safeguards
8. Accessories - Do not place the unit on an unstable surface 22. ESD Precaution - Take all normal electrostatic discharge to avoid falling. Use only Vicon recommended mounting accessories. precautions to avoid component damage during installation and operation. -
Page 6: Packing List
1. Iris lens connector plug for DC drive – 1 pc 2. Dust protective cap – 1 pc 3. Ferrite clamp – 2 pc 4. Manual – 1 pc 5. Installation CDs – 2 pc XX156-00-01 Rev 705 VN-755IP Camera... -
Page 7: Connectors And Controls
ViconNet network. When used as a single-channel camera (with no analog cameras connected), the VN-755IP delivers up to 30 fps. With the addition of 1-3 external connected, there is a maximum of 15 fps total. -
Page 8: Ethernet (Network Port)
4. ALARM (Alarm Input) and AUDIO (Microphone) This RJ-45 connector provides 4 sensor inputs and 1 microphone input to the camera/server. A Telco box and RJ-45 connector cable can be purchased separately as accessory kit Model No. VN-755IP-KIT, product code 8775. -
Page 9: To Connect A Microphone
NOTE: Users may select N.O and N.C. according to the equipment being installed. Four 1KΩ resistors are required and are included in accessory kit VN-755IP-KIT, which may be purchased separately. To connect a microphone: 1. -
Page 10: Network Led
This function may not operate properly if the object is too small compared to the area of the background. This function can be used with either the linear shutter (EE/ELC mode) or an autoiris lens (AI lens/ALC mode). XX156-00-01 Rev 705 VN-755IP Camera... - Page 11 4. Fixed iris or manual iris lenses may be used with the linear shutter (EE/ELC mode) when the scene brightness varies over a limited range. 5. Do not use the EE/ELC mode when an autoiris lens is installed. XX156-00-01 Rev 705 VN-755IP Camera...
-
Page 12: Alc Level Adjustment Potentiometer For Dc Drive Lens
2. If camera A's adjustment range is insufficient, adjust camera B's V-phase control push button in the opposite direction to camera A until they are in phase. 3. If these adjustments do not bring vertical sync from both cameras in phase, recheck the polarity of the power supply connections. XX156-00-01 Rev 705 VN-755IP Camera... -
Page 13: Back Focus Adjustment
Backfocusing Zoom Lenses 1. Install a lens and connect the camera to a monitor and power supply. If the lens is motorized, it must also be connected to a lens control. XX156-00-01 Rev 705 VN-755IP Camera... -
Page 14: Ccd Dust Protective Cap
Remove this cap before installing the lens. Do not handle or leave the camera with cap off. 14. CAMERA MOUNTING HOLE There are two mounting holes provided, one each on the top and bottom of the camera. 15. AUTOIRIS LENS CONNECTOR FOR DC DRIVE LENS XX156-00-01 Rev 705 VN-755IP Camera... -
Page 15: Viconnet Configuration
ViconNet Workstations can be used for live viewing and recording of network-streamed video. A network can be as simple as a single VN-755IP 4-Channel Camera connected to a ViconNet Workstation or can be complex with the addition of several networks interconnected via WAN. - Page 16 XX156-00-01 Rev 705 VN-755IP Camera...
- Page 17 XX156-00-01 Rev 705 VN-755IP Camera...
-
Page 18: Configuring The Network Settings
Configuring the Network Settings Note: Before starting, make sure that VNSetup.exe is installed on the configuring PC\workstation. the VNSetup is found on the included CD, VN-755IP Software. There are two ways to change the IP camera network settings: • Activating the camera for the first time: via VNSetup.exe application. -
Page 19: Upgrading Software Version
Verify that the camera is connected to the network and that it is active. From the workstation desktop, run the ViconNet application. After logging in, open the site setup selection window. Select the IP camera setup. XX156-00-01 Rev 705 VN-755IP Camera... -
Page 20: Network Settings Window
A priority screen is used to establish video quality and FPS levels. Refer to the ViconNet Workstation manual XX113-3X for complete information on configuration. A copy of the manual is found on the included CD, VN-755IP Software. XX156-00-01 Rev 705 VN-755IP Camera... -
Page 21: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 22: Coaxial Cable Recommendations
Let the required picture quality and cable distance provide a guide in choosing the best cable type. For cables other than the approved Vicon types below, contact the manufacturers listed below. Note that “BC” refers to bare copper and “TC” refers to tinned copper. -
Page 23: Twisted-Pair Cable
Twisted-Pair Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use a pure copper stranded conductor with or without a tin-plating to obtain a low DC resistance. Do not use cable with either steel or aluminum stranded conductor because they do not transfer signals effectively for long distances. -
Page 24: Network Cable
Network Cable Caution: Careful selection of proper cable is essential to obtain the best performance. Vicon assumes no responsibility for poor performance when cables other than the recommended types, or equivalent, are used. Materials Use pure copper stranded conductors to obtain a low DC resistance. The preferred insulation and cable jacket is Polyvinyl chloride (PVC). -
Page 25: Technical Information
- 24 hours normal activity with 50% detected movement over time, Normal compression and Quality Q5 (320 x 240 pixels NTSC, 384 x 288 pixels PAL) - Recording durations may vary based on actual scene activity. XX156-00-01 Rev 705 VN-755IP Camera... -
Page 26: Controls And Connectors
Network: RJ-45 CAT 5 (rear). See rear Panel diagram. Wire Size (AWG) Maximum Distance Annealed ft (m) Copper Wire 240 (73) 375 (114) 600 (183) 960 (293) 1500 (457) Table 2: Maximum Power Cable Distances XX156-00-01 Rev 705 VN-755IP Camera... -
Page 27: Vicon Standard Equipment Warranty
(bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion. Vicon reserves the right to make changes to its software in any of its products at any time and without notice. - Page 28 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
