Trotter

Unfolding the bicycle

Magnetic frame lock
Push the wheels away from each other to unlock the magnetic
frame lock.
(A) Metal locking plate
(B) Magnet
(C) Locking direction
(D) Locked position
Unfolding the frame
Spread the front and back parts of the frame until the frame is
straight and the hinge is closed.
Securing the frame clamp
Secure the frame clamp (A +B) by pushing it against the frame.
Make sure the round head screw snaps well into the frame clamp.
Then press the plastic locking cap into the frame clamp.
Unfolding and securing the handlebar
Fold the steering column upwards (C) and secure it with the
handlebar clamp (A). Make sure that the round head screw
snaps well into the handlebar clamp.
Then secure the handlebar clamp by turning the locking
ring (B) into the handlebar clamp (located around
the steering column at the height of the handlebar clamp).
Unfolding the pedals
Unfold the pedals by pushing them into a horizontal position.
The pedals will automatically go into the correct position.
